JEBG Series / Electron Beam Sources

Product catalog summary

Overview: This document outlines the specifications and features of JEOL's electron beam sources and power supplies, designed for high thermal efficiency in the optical and electronic industries. It also covers a deposition control system utilizing these electron beam sources.

Electron Beam Sources:

BS-60050EBS: Features reduced backscattered electrons, variable accelerating voltage, and a long-life filament, with easy maintenance and contamination-resistant design.
BS-60040VDGN: Offers variable accelerating voltage and techniques to prevent electric discharge, ideal for high-reproducibility evaporation.
BS-60030DGN: A general-purpose source with a high-rate crucible for metals.
JEBG-102UHO: Produces excellent melt spots, suitable for optical thin films.
EBG-203UB4H/6S: High power with large-area scanning capabilities, allowing simultaneous evaporation of multiple materials.

Power Supplies:

JST-F Series: High-performance, high-voltage power supplies with energy-saving SCR control, configurable for computer-controlled systems.

Controllers:

BS-64010SCT Scan Controller: Optimizes scan patterns for each material, improving melt spot quality with multiple scan modes and memory for up to 15 patterns per source.

Installation Requirements: Specifies maximum output, accelerating voltage range, electron beam deflection angle, and cooling water flow rate, emphasizing the need for specific environmental conditions.

Key Features:

Direct heating for high thermal efficiency.
Water-cooled copper crucible to prevent reactions.
Easy filament replacement.
High reproducibility and uniform film thickness through high-speed scanning.

Deposition Control System: Features control for two electron beam sources, compatible with DeviceNet and RS-232C communication, allowing external PC or sequencer control. Supports various patterns and emission-current control.

Control Units: Operates JST-F series power supplies via DeviceNet, with residual-field erasing and filament-monitoring functions.

Triple Source Controller: Enables simultaneous evaporation of three evaporants with high-speed scanning.

2 Point Controller: Allows alternate irradiation of two points, enabling simultaneous evaporation of two materials with adjustable rates.

Compliance: Products are controlled under Japan's export laws, requiring specific documentation for export licenses.

Contact Information: Provides contact details for JEOL offices and distributors worldwide.
