Sliding Vane Pumps

Product catalog summary

Overview: The document provides detailed specifications and features of various sliding vane pumps designed for diesel refueling and oil transfer, suitable for international and US markets. These pumps are engineered for different applications, including construction, forestry, and marine industries.

SR060 Submersible Diesel Refuelling Pump:

Flow Rate: 13 gpm (60 lpm).
Features: Faster refueling, compact design, debris tolerance, 2-year warranty, low maintenance, and IP68 sealed electrics.
Intelligent Control: Failsafe operation, automatic stop when the tank is full or empty, and immersion detection.
Performance Specifications: Duty cycle of 10 mins on and 5 mins off, ATEX certification, and various environmental and vibration tests.

FuelMaster 40 & By-Pass 40:

Flow Rate: 9.3 gpm (35 lpm) at 1500 rpm.
Features: Integral by-pass, fully assembled kit, suitable for large diesel vehicles, and safe storage.
Applications: Suitable for mounting on excavators, cranes, and other heavy machinery.

Rotary Vane Pump:

Flow Rate: 23 lpm.
Features: Self-priming, reversible, and meets marine ignition protection standards.
Specifications: Bronze body, vectra rotor, and Ryton vanes.

Hydraulic Oil Transfer Pump:

Flow Rate: 6.87 gpm (26 lpm).
Features: Self-priming, maximum differential pressure of 21.76 psi, and suitable for hydraulic oils.
Specifications: Aluminium body, sintered iron rotor, and PTFE filled Ryton vanes.

35l Diesel Refuelling Pump:

Flow Rate: 9 gpm (35 lpm).
Features: High head capability, self-priming, vibration tested, and IP55 protected motor.
Applications: Designed for small diesel vehicles and suitable for various oils.

50l Diesel Refuelling Pump:

Flow Rate: 13 gpm (50 lpm).
Features: High head capability, continuously rated, and IP55 protected motor.
Applications: Suitable for small diesel vehicles and various oils.

100l Diesel Refuelling Pump:

Flow Rate: 28 gpm (105 lpm).
Features: Faster refueling, high head capability, thermal overload protection, and IP55 protected motor.
Applications: Designed for large diesel vehicles and suitable for various oils.

Catalog excerpts

Untitled table.main {} tr.row {} td.cell {} div.block {} div.paragraph {}

Open the catalog to page 1

Untitled table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:4.00pt "Arial", sans-serif; } .font1 { font:6.00pt "Arial", sans-serif; } .font2 { font:7.00pt "Arial", sans-serif; } .font3 { font:4.00pt "Impact", sans-serif; } .font4 { font:5.00pt "Impact", sans-serif; } .font5 { font:7.00pt "Lucida Sans Unicode", sans-serif; } .font6 { font:8.00pt "Lucida Sans Unicode", sans-serif; } .font7 { font:9.00pt "Lucida Sans Unicode", sans-serif; } SLIDING VANE PUMPS SUBMERSIBLE DIESEL SLIDING VANE PUMPS SR060 SUBMERSIBLE DIESEL REFUELLING PUMP WITH INTELLIGENT CONTROL FOR INTERNATIONAL...

Open the catalog to page 3

Untitled table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:4.00pt "Impact", sans-serif; } .font1 { font:5.00pt "Impact", sans-serif; } .font2 { font:13.00pt "Impact", sans-serif; } .font3 { font:6.00pt "Lucida Sans Unicode", sans-serif; } .font4 { font:7.00pt "Lucida Sans Unicode", sans-serif; } .font5 { font:9.00pt "Lucida Sans Unicode", sans-serif; } SLIDING VANE PUMPS DIESEL SLIDING VANE / OIL TRANSFER PUMPS FUEL MASTER 40 & BY-PASS 40 | FOR INTERNATIONAL & US MARKETS Flow rate: Nominal 9.3 gallons/min (35 Liters/min) at 1500rpm. Self-priming from dry up to 4.9ft...
