Centrifugal Pumps

Centrifuga l Pumps Stainless Steel Pumps CYCLONE™ STAINLESS STEEL CENTRIFUGAL PUMP FOR International & US MARKETS The combination of reliability, performance, and silent operation is what makes the Cyclone™ range the class leader and why these robust pumps are supported by many major customers and OEMs worldwide. The Hybrid Cyclone™ model was developed in response to industry application requirements and our customers needs to increase the pump’s versatility and performance criteria. Features • Heavy duty robust design • Stainless steel construction • Long life DC motor • Silent running • Anti-clog...

CENTRIFUGAL PUMPS Stainless Steel Pumps 50840 Series dimensional drawings 3.07 (78.1) 4.82 (122.5) Unless otherwise stated dimensions in [ ] are in mm. 3.50 (89) 6.37 (161.9) 50850 Series dimensional drawings Unless otherwise stated dimensions in [ ] are in mm. T 3.07 (78.1) 4.39 (111.5) NP 3.50 (89) 6.26 (159.1) 50860 Series dimensional drawings Unless otherwise stated dimensions in [ ] are in mm. 4.39 (115.5) NPT 8.2 (208.4) 3.50 (89) s e c t i o n TWO | page 13

Centrifuga l Pumps Circulation Pumps COMMERCIAL CIRCULATION PUMP 59510 SERIES | FOR International & US MARKETS Applications • 12.5 liters/min (3.3GPM) @ 0.12 Bar (1.74PSI) • Magnetic Drive - sealed pump chamber • Ignition protected • Meets EMC requirements • Connections for 19mm (3/4”) ID Hose • Continuously rated • Pumps water at 212°F (100°C) • Long life brushless DC motor Performance Pressure/Head psi (bar) 1.5 3.00 (0.20) 1.2 2.25 (0.15) 0.9 1.50 (0.10) 0.6 0.75 (0.05) 0.3 0 130 (500) 0 260 (1000) Amps 3.75 (0.25) 0 363 (1400) Flow gpm (lpm) models Model #s Certification Voltage Fuse Size...

CENTRIFUGAL PUMPS Mag Drive Pumps NEW! GPR10/15 | FOR International Markets Designed for continuous recirculation of carbonated water, aggressive chemicals, chilled water, pure or precious liquids in high pressure systems Features • Manufactured in chemically resistant thermoplastics • Operating at an optimum flow rate of 1.3 gallons/minute (5 liters/minute) • Magnetic coupling provides an energy efficient thermal shield, minimizing heat transfer to pumped fluid • Temperature stability and product purity ensured • Leak-free continuous operation • IPX5 motor enclosure • Low condensation • Zero...

Centrifuga l Pumps NEW! Mag Drive Pumps NEMP20/12 | FOR US and International Markets For applications requiring safe, leak-free, high head, continuous flow of aggressive chemicals, acids, Alkalis, solvents, pure and chilled fluids. Features • Manufactured in chemical resistant thermoplastics – entirely non-metallic • Multistage versions developed for high head with low flow • Magnetic couplings provide and energy efficient thermal shield, minimizing heat transfer to the pumped fluid • IPX5 standard motor housing • Deep groove ball bearings • Variable pump body orientation and mounting foot positions...

CENTRIFUGAL PUMPS Mag Drive Pumps NEW! NEMP20/18 | FOR US and International Markets For applications requiring safe, leak-free, high head, continuous flow of aggressive chemicals, acids, Alkalis, solvents, pure and chilled fluids. Features • Manufactured in chemical resistant thermoplastics – entirely non-metallic • Multistage versions developed for high head with low flow • Magnetic couplings provide and energy efficient thermal shield, minimizing heat transfer to the pumped fluid • IPX5 standard motor housing • Deep groove ball bearings • Variable pump body orientation and mounting foot positions...

Centrifuga l Pumps NEW! Mag Drive Pumps NEMP25/5 | FOR US and International Markets For applications requiring safe, leak-free, continuous flow of aggressive chemicals, acids, alkalis, sterile and chilled fluids. Features • Manufactured in chemical resistant thermoplastics – entirely non-metallic • Magnetic couplings provide an energy efficient thermal shield, minimizing heat transfer to the pumped fluid • IPX5 standard motor housing • Deep groove ball bearings Specifications Pump Design Model #s CErtification Voltage 456952 CE 230V 1Ph 50Hz 456950 CE 110V 1Ph 60Hz Contact factory for custom...

CENTRIFUGAL PUMPS Mag Drive Pumps NEW! NEMP40/4 | FOR US and International Markets For applications requiring safe, leak-free, continuous flow of aggressive chemicals, acids, alkalis, sterile and chilled fluids. Features • Manufactured in chemical resistant thermoplastics – entirely non-metallic • Magnetic couplings provide an energy efficient thermal shield, minimizing heat transfer to the pumped fluid • IP54 standard motor housing. IP55 version available. • Deep groove ball bearings NEW models Specifications Model #s CErtification Description Port DETAILS Pump Design Magnetically Coupled Centrifugal...

Centrifuga l Pumps Mag Drive Pumps NEW! NEMP40/6 | FOR US and International Markets For applications requiring safe, leak-free, continuous flow of aggressive chemicals, acids, alkalis, sterile and chilled fluids. Features • Manufactured in chemical resistant thermoplastics – entirely non-metallic • Magnetic couplings provide an energy efficient thermal shield, minimizing heat transfer to the pumped fluid • IPX5 standard motor housing. IP55 version available. • Deep groove ball bearings Specifications Pump Design Flow Rate (Runout) Temperature Range 230V 1Ph 50Hz 5.6” H x 7.9” L x 4.0” W (143mm...

CENTRIFUGAL PUMPS Mag Drive Pumps NEW! NEMP50/7 |FOR US and International Markets For applications requiring safe, leak-free, continuous flow of aggressive chemicals, acids, alkalis, solvents, sterile and chilled fluids. Features • Manufactured in chemical resistant thermoplastics – entirely non-metallic • Magnetic couplings provide an energy efficient thermal shield, minimizing heat transfer to the pumped fluid • IPX5 standard motor housing • Deep groove ball bearings NEW models Specifications Model #s CErtification Description Port DETAILS Pump Design Magnetically Coupled Centrifugal Pump 456904...
