BIO DILUTOR
1 / 2Pages

TECHNICAL DATA Motor Syringe volume: Maximum flow speed: Minimum volume step: Use of disposable tip: Air bubble volume: Sample volume: Stepping. Angle 7.5°. 9 W 10, 5, 2.5 or 1 ml autoclavable 4 ml/s with 10 ml syringe 1/1000 of the total volume of syringe Programmed from the beginning of process Programmable. Programmable. Limited to the tip volume (1300 µl) 1% of the springe volume used. Warning notice if it is less than 5%. Programmable from 1:1 to 1:1000 Better than 1% even for dilutions using more than one single syringe stroke Serial RS 232, programmable 100/240 V, 50/60 Hz 40 W 30x30x20 cm 11,8x11,8x7,8 cm 6 kg/13,2 lb FOR ADVANCED ONLY Balance communication: Gravimetric dilution: Linked programs: Serial RS 232, programmable By specific weight of solvent Up to 9 Min. sample volume: Dilution factor: Reproductibility: Printer communication: Mains: Power: Dimensions (WxHxD): Specifications subject to change without prior notice ORDERING INFORMATION BIO DILUTOR with handgrip for tips, complete liquid circuit with bottle, 10 ml syringe and box of 60 units of gamma-irradiated tips. Specifye mains required (the Cat.No. may change) CONSUMABLES Syringe complete (10 ml). Stainless steel plunger Syringe barrel (10 ml) +2 silicon washers Box of 24 containers of 60 tips each irradiated with gamma rays Bag 1000 disposable tips not irradiated Bag of 10 stainless steel holders (60 tips) Box of 24 empty containers Box of 1000 irradiated straws Stainless steel delivery tube for hand held Stainless steel delivery tube for 100 ml tips Handgrip for straws with stainless steel delivery tube, without silicone tubing (foot pedal needed) Foot pedal Autoclavable stand for syringes without syringe and adapter (no needed for 10 ml) Autoclavable syringe, 5 ml and adapter Autoclavable syringe, 2.5 ml and adapter Autoclavable syringe, 1 ml and adapter Cable BIO DILUTOR-printer Cable BIO DILUTOR ADVANCED balance OPTIONAL ACCESSORIES (State balance manufacturer and model when ordering) Contact us in internet. To see how the instruments works in a multimedia demonstration, to buy instruments, accessories or consumables on-line visit our web page: The IUL instrument owners who are registered in our web will have access to extra services like example of microbiology applications with our instruments, software updates, direct technical service and more.

Sterile conditions The periodic cleaning is absolutely essential in microbiology laboratories. All the parts of the liquid circuit of BIO DILUTOR are autoclavable. Removal and reinstalling this liquid circuit takes only a few seconds. Take the sterile tip from the container Take the sample and the air bubble is created When the BIO DILUTOR takes the sample an air bubble is generated to prevent the mix between the sample and the solvent. Once the operation has been done the tip is rejected. Dispense the sample and the solvent Two interchangeable handgrips The handgrip for tips allows the tip...
