N.A. Woodworth Tork Lok Collet (Mandrel)

Product catalog summary

Overview: This technical catalog from N.A. Woodworth, an ITW Workholding Company, details Tork-Lok products, including arbors, collets, and fixtures, with a focus on both long and short series models.

Specifications: The catalog provides comprehensive dimensions and specifications for various arbor and collet models. Key parameters such as A, B, C, D, E, G, K, and range are detailed to indicate size and compatibility.

Collet Ranges: It specifies collet sizes and lengths, highlighting their interchangeability across different arbors, ensuring precision and accuracy.

Replacement Components: Replacement kits are available, including expanders, connectors, retaining rings, lock pins, and dirt seals, essential for maintaining functionality.

Operating Instructions: Detailed instructions cover mounting fixtures, adjusting expanders, and changing arbor assemblies, emphasizing correct mating of collet and arbor flats for efficiency.

Safety and Maintenance: Safety stops prevent over-expansion and damage. Guidelines for preload settings and special work stop considerations are provided.

Air-Operated Models: Instructions include maintaining air pressure at 70 P.S.I. and guidelines for changing collets and interchanging assemblies.

Recommendations: Oversize collets are recommended only for light turning or grinding operations. Contact information is provided for special requirements.

Specifications and Procedures: Instructions for disengaging the drawbar, mounting assemblies, and ensuring clean, oiled threads are included.

Contact Information: Contact details for various Forkardt and ITW Workholding locations are provided for further assistance.

Catalog excerpts

N.A. Woodworth Tork Lok Collet (Mandrel)-1

An ITW Workholding Company Tork-Lok ArborsՕ Collets Fixtures ՓThe Original >

Open the catalog to page 1

N.A. Woodworth Tork Lok Collet (Mandrel)-7

The expansion safety stop is fixed in all stylesand requires no adjustment. The contraction or loading position safety stop is adjusted to suit the part being chucked. > All collets are manufactured to include a preload. Collets should not be adjusted below the range minimum for that collet. Preloads are .008 average on sizes from .500-.874 and .015 from .875-4.467. Note: All Tork-Lok arbor applications require a part stop. > Note: If Restrictor Type Stop is used, a special Restrictor Expander isrequired. Contact Combination Work Stop and Retaining Sleeve... Restrictor Type Work Stops are necessary...

Open the catalog to page 7

N.A. Woodworth Tork Lok Collet (Mandrel)-8

FORKARDT DEUTSCHLAND GMBHHeinrich-Hertz-Str. 7 D-40699 Erkrath Tel:(+49) 211-25 06-0 Fax:(+49) 211-25 06-221 E-Mail:[email protected] CHUCK2155 Traversefield Drive Traverse City, MI 49686, USA Tel:(+1) 231-995-8312 Fax:(+1) 231-947-4953 E-Mail:[email protected] FORKARDT SCHWEIZ AGIndustriestrasse 3 CH-8307 Effretikon Tel:(+41) 52-3 55331 Fax:(+41) 52-3 43540 E-Mail:[email protected] USA2002 Stephenson Highway Troy, MI 48083, USA Tel:(+1) 800-794-6190 Fax:(+1) 248-743-4401 E-Mail:[email protected] FORKARDT FRANCE S.A.R.L.28 Avenue de Bobigny F-93135 Noisy le Sec Cdex Tel:(+33)...

Open the catalog to page 8
