QLC/QLK Series Power Chucks
These chucks feature an improved backlash-free wedge-hook system and centrifugal force compensation. They are 30-40% lighter than comparable chucks and include a patented slide system for stability and precision. The chucks have a forced lubrication system and improved sealing to minimize lubrication loss. Variations include large through hole, long stroke, and compensating versions.

VC Quick Change Jaw System
This system enhances productivity by simplifying jaw change setup times, allowing changes in approximately 5 seconds. It supports both OD and ID clamping with precise repeatability under high clamping pressures.

FNC High Accuracy Universal Power Chuck
Featuring a patented wedge-hook design for high gripping forces, this chuck includes a quick change jaw system and a one-piece rigid chuck body for long service life. It maintains concentricity and repetitive accuracy, compatible with existing F-style jaw systems.

Index Chucks
Designed to reduce multi-axis part turning to a single operation, these chucks are suitable for parts like universal joints and valves. They reduce operations and investment capital, with available hydraulic control packages and machine integration.

KCHP/S High Precision Power Chucks
These chucks are designed for cylindrical grinding, hard-turning, or finishing operations, featuring a high precision wedge-hook design and a ball positioning system for quick jaw changes. They offer TIR repeatability of 2 microns and are fully sealed for lasting accuracy.

Cutting Tool Grinding Chuck
This high precision chuck offers an extended clamping range for tool grinding machines, with a clamping repeatability of 0.005mm and a range of 2mm to 17mm.

LZK Multi-Blade Collet Chucks
These chucks provide a large clamping range and tight production tolerances, suitable for clamping thin-walled workpieces without deformation.

EM+D Mandrels
The EM Series features interchangeable clamping sleeves with a double conical expansion for perfect clamping geometry. The D Series offers accuracy, shorter setup times, and flexibility with a wide clamping range.

SKM Electronic Gripping Force Meter
This device measures static gripping force with high accuracy, suitable for chucks with 2 to 6 jaws, utilizing advanced C-MOS technology.

"HCT" Series Closed Center Hydraulic Cylinder
These cylinders offer optimum speed and operating force, with features like through-hole for coolant, oil, or air, and a max operating force of 80 Bar.

Worldwide Locations
Contact information for Forkardt locations in the USA, Germany, France, Switzerland, and N.A. Woodworth is provided.
