THE HIGHLIGHTS Linear Unit KLE 5 A highly integrated linear axis that brings motion to the tightest of spaces item Conveyor Belt System Perfect protection thanks to ESD-safe flat conveyor belts and timing belts LED Strip RGB High-quality indicator lights for industrial use Sliding doors Build space-saving door segments with ease using item clamp profiles

Linear Unit KLE 5 40x40 LR A compact linear unit built into the installation space of a Profile 40x40! Linear Unit KLE 5 40x40 LR with roller guidance and dynamic timing-belt drive is designed for payloads up to 250 N and brings motion to the smallest of spaces. Despite its compact dimensions, Linear Unit KLE 5 40x40 LR has all the key features of item Linear Units KLE – the roller elements run inside the profile and are concealed by the timing belt. With the exception of the carriage, all moving parts are safely out of reach. This enhances occupational health and safety and reduces soiling...

In detail: Linear Unit KLE 5 40x40 LR To squeeze everything into its compact dimensions, Linear Unit KLE 5 40x40 LR is packed full of technical highlights. Use this interactive graphic to discover all the benefits it offers.

Drive Sets NEMA 24 Do you need to use item linear units with NEMA 24 stepper motors? That’s no problem when using new Drive Sets NEMA 24! Four new plug-and-play solutions ensure NEMA 24 electric motors can be connected up without any additional machining: Drive Set GSF 8 40 NEMA 24 Drive Set KLE 5 40x40 NEMA 24 Drive Set ZU 5 40 D30/D12 NEMA 24 Drive Set 6 60 D30/D12 NEMA 24 These products ensure that item linear units with timing-belt and spindle drives can be used directly with motors that satisfy NEMA standard ICS 16-2001. For motors to the NEMA 24 standard Optimum connection to item...

item MotionDesigner® item MotionSoft® Speed or precision? item MotionDesigner® does both! When designing and selecting linear units, you can now choose between standard and expert modes. When using expert mode, you can map every aspect of a motion task in detail – load distribution, several waypoints and acceleration curves are factored into calculations precisely. By contrast, when using standard mode, item MotionDesigner® works with default values. To get a quick overview, you only need to enter a few basic details such as mounting arrangement, weight, travel distances and travel times....

Find your linear unit fast in standard mode item MotionDesigner® now offers a standard mode that uses the kind of preliminary settings common to most applications so users can carry out an initial selection for a design or get a quick overview. This means that only a few details such as mounting arrangement, transport weight, travel distances and travel times need to be entered to create an approximate design. Detailed design in expert mode The expert mode of item MotionDesigner® gives you access to all detailed calculations so you can map out in detail all the aspects of a motion task when...

Profiles XMS M45 R40/45° Two concepts – one contour! Line XMS profiles are available with an internal cable conduit and with a cable conduit that can be accessed from outside. Two new profiles now make it easy to combine the cross-sections harmoniously. Profiles XMS M45 feature a cable conduit that is open to the outside and can be sealed shut with an aluminium cover. Covers with a 45° chamfer and R40 rounded edge are often used on corner profiles. Profile X 8 40 80x80-45° M45-45° - XMS and Profile X 8 40 80x80-R40 M45-45° - XMS feature these outer contours and have a cable conduit that is...

Face Plate M45 Machine operation made easy! The new Face Plates XMS M45 both provide a surround for operating elements in the Modul 45 design and cover over the integrated cable conduit of Line XMS profiles. As a result, there is no need to cut openings into the cover profiles. Simply clip an M45 element into the cable conduit, wire up the application then push a Face Plate XMS M45 into place. Job done! Face Plate 80 M45 1 Gang - XMS and Face Plate 80x80-45° M45 1 Gang - XMS are available for cable conduits that are open to the outside. Cap R40/45° M45 - XMS is used to create a smooth...

Angle Bracket 6 120x120-30 Al M6 and fastening set Extra hold with a flick of the wrist! Use sturdy Angle Bracket 6 120x120-30 Al M6 to create a friction-based connection between Line 6 profiles without having to carry out any machining work. When a construction is under particular strain, it can be fitted to provide additional support for profiles connected at a right angle and prevent displacement. The angle bracket can be retrofitted using Fastening Set for Angle Bracket 6 120x120 M6. The one-piece profile bar with four threads makes it easier to fit the bracket rapidly to a Line 6...

Standard-Fastening Set 6 K Insert panels directly into the groove! When using Standard-Fastening Set 6 K to connect together Line 6 profiles at a right angle, all the profile grooves are left clear to accommodate panel elements. This means you can insert panels rapidly into the grooves of a Line 6 profile without having to trim the corners. This compact version of Standard Fastener 6 uses a plastic spacer instead of a connecting plate that projects into the groove. This is helpful when building doors and hatches that have a panel infill, particularly when incorporating central struts....

Profile 8 light, not anodized Selected Profiles 8 light are now also available without their usual protective anodized surface covering. This is useful if you want to finish the profile with an anodized surface coating in a special colour or if you want to omit the oxide layer to improve the earthing of your profile frame. Profiles 8 light, not anodized are construction profiles in the modular dimension of Line 8. They are available in the following cross-sections: 40x40, 80x40 and 80x80. Non-anodized profiles are identical to anodized profiles in terms of their functionality. However, a...
