DELTAREG LINE: strapping systems

DELTAREG LINE: strapping systems

Product catalog summary

Overview: This document provides technical specifications and features of various strapping machines and tools manufactured by Italdibipack S.p.A. These machines are designed for different strapping needs, including automatic, semi-automatic, and pallet strapping.

Specifications:

Automatic Arch Strapping Machine (Delta Reg AA 200, AA 202 X, AA 55 ARP): Offers 26 cycles per minute with a standard arch size of 850x600 mm. Strap tension ranges from 5 to 70 kg, and it supports PPL, PET, and metallic straps of 9/12/15 mm. The machine operates on a 220V power supply and weighs 220 kg.
Hi-speed Automatic Arch Strapping Machine: Capable of 50 cycles per minute with a standard arch size of 700x500 mm. It features a softer strap tension range of 1.5 to 40 kg and uses PPL straps of 5/9 mm. The machine is lighter at 125 kg and has an adjustable working-plate height.
Pallet Strapping Machine: Also performs 50 cycles per minute with a strap tension range of 15 to 70 kg. It supports PPL and PET straps of 9/12/15 mm and is equipped with steel-roller movement for ease of use.
Semi-automatic Strapping Machine (Delta Reg AA 55 AR BTL): Provides 1.5 cycles per second with a strap tension range of 0.6 to 45 kg. It supports various strap sizes and features a steel-roller movement with a top-press for securing items.

Features:

Machines are manufactured according to CE standards.
Automatic strapping can be operated by a pedal, button, or photocell.
Custom arch sizes are available upon request.
Technical data is subject to change without prior notice.

Contact Information: Italdibipack S.p.A., Via Europa 35, 20010 Pogliano Milanese (MI), Italy. Tel: ++39/02/9396461, Fax: ++39/02/93549494, Website: www.italdibipack.com, Email: [email protected]

Catalog excerpts

apparecchi e materiali tendireggia I hand strapping tools and materials reggia in PPL, PET e metallica I PPL, PET and metallic strap Macchine fabbricate Machines made strapping carts Via Europa 35 - 20010 Pogliano Milanese (MI) Italy www.italdibipack.com - e-mail: [email protected] macchine, apparecchi e materiali per reggiatura trapping systems, tools and materials

Open the catalog to page 1

DeltaReg AA 200 Reggiatrice automatica ad arco / Automatic arch strapping machine Caratteristiche tecniche / Specifications Reggiatura / Output Arco standard / Standard arch Tensionamento reggia / Strap tension Reggia utilizzata / Strap (PPL, PET, metallic/a) Tensione di alimentazione / Power supply Altezza piano-tavolo / Working-plate height Dimensioni ingombro / Overall dimensions LxWxH Peso macchina / Machine weight DeltaReg AA 55 ARP DeltaReg 26 cicli/cycles al/per min. mm 850x600 kg 5÷70 mm 9/12/15 220V 1Ph/50 Hz/ 0,9 kW mm 810 mm 1412x600x1540 kg 220 AA 130 A1 Reggiatrice per bancali /...

Open the catalog to page 2
