Rotating Wing Dust Filter Systems

Product catalog summary

Certifications
Isımsan's Rotating Wing Dust Filter Systems are manufactured in compliance with several international directives and regulations, including ISO 9001 for quality management, ISO 14001 for environmental standards, and ISO 3834 & 14731 for welding technology. The systems also adhere to CE machinery and pressure vessel directives, ATEX product line, EHEDG hygiene guidelines, GMP, FDA, and EAC standards.

Product Information
The dust filter system is designed for various manufacturing processes, ensuring high hygiene and quality standards. It is applicable in industries such as food, animal feed, chemicals, and building materials. The system features a cylindrical shape with a conical dust collector, made from stainless steel, and utilizes a compressed air rotary wing system for efficient and quiet cleaning.

Filter System Description
The rotating filter technology provides efficient cleaning by detaching the filter cake along the entire filter cartridge. Key features include uniform cleaning, low noise levels, and minimal compressed air consumption. The system is distributed worldwide and includes options like a frame and platform, automatic filter cake discharging, and remote control.

Jet Pulse Rotating Wing Specifications
Measurements: Ø 320 L: 600
Air permeability: 166 (± 33) l/m²*s
Filter sensitivity: ~1 μm
Material: 100% Polyester
Cartridge material: Aluminium
Air pulse rate: 1.5 s ~ 3 s
Pulse valve: Atex ex-proof

Construction Details
Housing material: AISI 304, stainless steel
Surface: Polished, mirror polished
Cleaning pulse duration: 1.5 s ~ 3 s
Air speed: 33 m/s
Minimum particle size: 0.02 mm
Dimensions and capacities vary between Type A and Type B, with dust bucket volumes of 60 liters and 70 liters, and air volumes of 2,500 m³/h and 4,000 m³/h respectively.

Components
The system includes components such as an acoustic hood, blow-out pipe end, fan, maintenance doors, clean air section, jet pulse wings, untreated gas chamber, cartridge, dust section, dirty air inlet, and dust bucket.

Worldwide Support
Contact information for sales and support is provided, including email, phone, and physical address in İzmir, Turkey.

Catalog excerpts

Rotating Wing Dust Filter Systems

Open the catalog to page 1

PRODUCT INFORMATION The dust filter system is suitable for a wide range of manufacturing processes. The high-quality processing, the simple operation and a very efficient dust filter system meets highest hygiene and quality standards. APPLICATIONS Food Animal feed Chemicals Building materials DESCRIPTION The dust filter system has a cylindrical shape with a downwardly conical dust collector. The material is made of stainless steel. The heart of the system is a compressed air rotary wing system. This extremely efficient and quiet cleaning system consists of wing blades, which rotate inside the...

Open the catalog to page 2

FILTER SYSTEM The rotaring filter technology is an extremely efficient cleaning system which detaches the filter cake over the entire length of the filter cartridge. FEATURES / FILTER SYSTEM JET PULSE ROTATING WING Material: Aluminium Air pulse rate: 1.5 s ~ 3 s Pulse valve: Atex ex-proof CARTRIDGE Material: 100% Polyester Thickness (mm): 0,8 (± 0,1) Filter sensitivity: ~1 μm Air permeability: 166 (± 33) l / m2 * s Measurements: Ø 320 L: 600 CHARACTERISTICS Extremely efficient Uniform cleaning Low noise level Minimal compressed air consumption Worldwide distribution OPTIONS Frame and platform...

Open the catalog to page 3

CONSTRUCTION DETAILS Housing material: AISI 304, stainless steel Not threated, polished, mirror polished Dimensions: Dimensions: Dust container volume: Volume Dust Bucket: Filter hair flow: Air Volume:

Open the catalog to page 4

WORLDWIDE SUPPORT E-MAIL : sales @isimsan.com.tr PHONE : + 90 232 877 05 82 Address: Cumhuriyet Mah.9081 Sok. No:59/1 Ulucak Kemalpaşa İZMİR
