Intel® Server Board S1200BT family Intel® Server System R1304BT family Intel® Server System P4304BT family Intel® Server Chassis P4304 family Product Brief An entry-level family of general-purpose server products designed for small to mediumsized business applications, including 1U rack systems supporting advanced management features and rich I/O. Key Features l Supports Intel® Xeon® processor E3 1200 product family (including lower power processors) l Highly-scalable DDR3 memory (up to 4 DIMMs) l Up to 5 slots high-speed PCI Express* 2.0 I/O (optional I/O module for 6 total I/O slots) l Highly-flexible network and storage configurations l Upgradable Intel® Remote Management Module supporting remote KVM, and dedicated NIC module Target Applications: Small and medium-sized business applications including web servers, file and print servers, e-mail servers, storage servers and vertical-specific business applications. Also suitable for High Performance Computing (HPC) and embedded applications.

Open the catalog to page 1

Features and Benefits • Supports Intel® Xeon® processor E3 1200 product family Delivers increased, intelligent and energy-efficient performance on demand • Fast, scalable and energy-efficient DDR3 memory Up to 4 DIMMs unbuffered DDR3 ensure ample capability and energyefficient performance for any application For S1200BTL models • Expandable I/O architecture Up to 5 I/O slots, including up to four high-speed PCI Express* 2.0 slots, provide flexible expansion with optional Intel® I/O SAS Module available • Rich I/O for rack deployment Mezzanine slot for internal SAS module provides excellent...

Open the catalog to page 2

Order Code S1200BTL S1200BTS Form Factor ATX (12” x 9.6”) uATX (9.6” x 9.6”) Processors1 Intel® Xeon® processor E3 1200 product family Intel® Xeon® processor E3 1200 product family Chipset Intel® C204 chipset Intel® C202 chipset Memory Capacity Four DDR3 DIMM sockets (Unbuffered only) l Two channel native (1066/1333MHz) Four DDR3 DIMM sockets (Unbuffered only) l Two channel native (1066/1333MHz) Storage Six SATA ports (2x6 Gbps, and 4x3 Gbps) via Intel® C204 chipset with Intel® Embedded Server RAID Technology / Intel® Rapid Storage Technology Six SATA ports (3 Gbps) via Intel® C202 chipset...

Open the catalog to page 3

Intel® Server System R1304BTLSHBN Technical Specifications Order Code R1304BTLSHBN R1304BTLSHBNNA Form Factor 1U Rack Server Board S1200BTL Drive Bays Four hot-swap 3.5’’ SAS/SATA HDDs Optional slim-line optical drive System Cooling 3 x 40mm fixed fans with duct Power Supply 350-watt non-redundant power supply Add-in Card Support One low profile PCI Express* 2.0 x8 through Riser card in slot 6 I/O Expansion Module Support Optional SAS Module Dimensions (H x W x D) 17.24” x 1.75” x 21.8” (438mm x 45mm x 553mm) Components Included *Heat sinks not included l Intel® Server Board S1200BTL l...

Open the catalog to page 4

R1304BTLSFAN R1304BTSSFAN Order Code R1304BTLSFAN R1304BTLSFANNA R1304BTSSFAN R1304BTSSFANNA Form Factor 1U Rack 1U Rack Server Board S1200BTL S1200BTS Drive Bays Four fixed 3.5’’ SATA HDDs Optional slim-line optical drive Four fixed 3.5’’ SATA HDDs Optional slim-line optical drive System Cooling 3 x 40mm fixed fans with duct 3 x 40mm fixed fans with duct Power Supply 250-watt non-redundant power supply 250-watt non-redundant power supply Add-in Card Support One full height PCI Express* 2.0 x8 through Riser card in slot 6 One full height PCI Express* 2.0 x8 through Riser card in slot 4 I/O...

Open the catalog to page 5

Intel® Server System P4304BT Technical Specifications Order Code P4304BTLSFCN P4304BTLSHCN P4304BTSSFCN Form Factor 4U Pedestal 4U Pedestal 4U Pedestal Server Board S1200BTL S1200BTL S1200BTS Drive Bays Up to four 3.5’’ fixed SAS/SATA HDDs Up to four 3.5’’ hot-swap SAS/SATA HDDs Up to four 3.5’’ fixed SAS/SATA HDDs Peripheral Bay(s) Media Bays (3 x 5.25”) Media Bays (3 x 5.25”) Media Bays (3 x 5.25”) System Cooling One 92mm rear chassis fan One 92mm rear chassis fan One 92mm rear chassis fan Power Supply 365W high efficiency non-redundant power supply 365W high efficiency non-redundant...

Open the catalog to page 6

Order Code P4304XXSFCN P4304XXSHCN Form Factor 4U Pedestal Drive Bays Up to four 3.5’’ fixed SAS/SATA HDDs Up to four 3.5’’ hot-swap SAS/SATA HDDs Peripheral Bay(s) Media Bays (3 x 5.25”) System Cooling One 92mm rear chassis fan Power Supply 365W high efficiency non-redundant power supply Tool-less features Peripherals bays, optional hot-swap bays, power supplies, PCI slots Bezel Features Customizable panel options Customizable panel options Lockable Front Connectors 2 x USB Pedestal Dimensions (H x W x D) 17.24’’ (438mm) x 6.81’’ (173mm) x 21.5’’ (546mm) Rack Dimensions (H x W x D) 6.81’’...

Open the catalog to page 7

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. UNLESS...
