Engineering Air Systems & Packaged Solutions Over 60 years of experience managing and implementing engineered to-order air packages for complex technical requirements Engineering Project Solutions www.ingersollrand.com ©2024 Ingersoll Rand. All Rights Reserved. All trademarks are the property of Ingersoll Rand

Contents 01 Introduction 1.1 Ingersoll Rand Profile 1.2 Our Scope 1.3 Industries 02 Added Values 2.1 Our Added Values at a Glance 2.2 Expertise in EPC Contracts 2.3 Project Management 2.4 Installation Solutions 2.5 Turnkey Installations 2.6 Quality Standards 2.7 Global Presence 2.8 References 03 Products 3.1 Air Compressor Packages 3.1.1 Rotary Screw Compressors 3.1.2 Reciprocating Compressors 3.1.3 Centrifugal Compressors 3.2 Air Dryer Packages 3.2.1 Adsorption Air Dryers 3.2.2 Refrigerant Air Dryers 3.2.3 External Heated Blowers 3.3 Nitrogen Generation Packages 3.3.1 PSA Systems 3.3.2 Membrane...

Engineering Project Solutions www.ingersollrand.com ©2024 Ingersoll Rand. All Rights Reserved. All trademarks are the property of Ingersoll Rand

1.1 Ingersoll Rand Profile Ingersoll Rand is a global market leader with a broad range of innovative and mission-critical air, fluid, energy, specialty vehicle and medical technologies, providing services and solutions to increase industrial productivity and efficiency. Since merging with Gardner Denver in early 2020, we have more than 300 years of combined experience and innovative expertise. Today’s Ingersoll Rand brands offer market-leading solutions and services to help make life better. Customers rely on our proven products in a variety of industries and markets across the globe. Ingersoll...

1.2 Our scope Through the years, we have developed our know how and ability to support our customers globally, and today we are able to provide a range of bespoke services. As a company, we will continue to offer a full suite of solutions for Air and Gas with the following products in scope: 1. Air Compressors • Screw Compressors • Centrifugal Compressors • Reciprocating Compressors • Rotary Vane Compressors • High Pressure Products • Reciprocating Compressors 2. Air Treatment • Desiccant Air Dryers (Heatless, External Heater, Heater Blower and Non-purge) • Refrigerant Dryers • Hybrid Packages...

1.3 Industries With more than a century of application experience and a range that covers every major technology, we can advise on, design, and supply the right machine for a range of industries: • Power Generation: hydroelectric, nuclear, coal, cogeneration, gas, renewable energy plants, waste-to-energy and others. • Oil & Gas: onshore, offshore, midstream. • Hydrogen Production Plants. • Chemical & Petrochemical: ammonia, ethanol, sulfuric acid, propane, carbon capture, propylene and others. • Water: water desolation, water treatment and others. • Mining: coal, gold, silver, copper and others....

Engineering Project Solutions www.ingersollrand.com ©2024 Ingersoll Rand. All Rights Reserved. All trademarks are the property of Ingersoll Rand

2.1 O ur Added Values at a Glance Engineering Project Solutions www.ingersollrand.com ©2024 Ingersoll Rand. All Rights Reserved. All trademarks are the property of Ingersoll Rand

2.2 Expertise in EPC Contracts Ingersoll Rand’s Engineering Project Solutions has provided specialized custom compressed air and nitrogen generation packages to international EPC contractors and engineering companies across a range of industries. Using the extensive experience that we have gained by working with EPC companies, Ingersoll Rand has developed the capabilities to carry our complex projects that are tailored to our customers’ requirements. Engineered for performance, our range of equipment is built to provide maximum efficiency, reliability and uptime. We are a leading global business...

2.3 Project Management Ingersoll Rand offers a complete project management service, including equipment installation and integration services. Our project management team of expert engineers control the whole process, from the design through to assembly, commissioning and start-up; including technical & quality management. Ingersoll Rand supports you throughout the project lifecycle EPC* Design phase. Specification & Product Customization Installation, Commissioning & Start up Project Management and Quality Assurance Maintenance Global Presence & Local Support *Engineering, Procurement and Construction...

2.3 Our Standard Project Execution Procedure Provided Services by Project Phase DESIGN . . . . Basic and detailed design engineering Equipment modification to customer requirement Project integration Quality, environmental and safety management PROJECT MANAGEMENT . Documentation to customer requirements (mechanical, electrical, I&C, quality, logistics, etc.) . Preparation of as built Drawings: P&ID, general arrangement, sectional drawings and 3D modelling . Complete assembly of the package, including piping and control of the installation (PLC) . Preparation of Installation, operation and maintenance...

2.4 Installation Solutions Ingersoll Rand can custom design and manufacture your equipment package including components such as: structural baseframe, machinery mounting pads, piping, tubing, electrical wiring, instrumentation, and controls. The different installation types are purpose designed in accordance with customer specifications and applicable ISO/ API standards and to major international codes and standards. Container • Ambient conditions inside the shelter controlled • Compact design Skid • Easy transportation • Connection points with customer at skid edge: inlet/outlet, make-up water...

2.5 Turnkey Installations At Ingersoll Rand we know that every customer has unique necessities. Every machine can therefore reflect the particular requirement of each customer. Ingersoll Rand Air and Nitrogen Packages are also designed to operate in harsh environments. Our equipment is engineered to face the most extreme ambient temperatures and extreme environmental conditions. Modifications A wide variety of options can be customized to meet even the most demanding customer requirements: • Outdoor Installation • HAT (55oC ambient temperature) • MV Motors • ATEX Certified Motors • PLC Control...
