Specifications
The 2145QiMAX Impactool operates at 6.2 bar (90 psi) with a 3/4 inch drive size. It features a friction ring and through hole socket retainer. Other versions include extended anvils and ATEX models. The tool delivers a working torque of 200 - 900 ft-lb in forward and 200 - 1,000 ft-lb in reverse, with maximum torques of 1,100 ft-lb and 1,350 ft-lb respectively. It has a free speed of 6,300 rpm and 1,150 impacts per minute.

Air System
The air inlet is 3/8 inch NPT with a minimum hose size of 1/2 inch. Average air consumption is 8.5 CFM, increasing to 32 CFM under load.

Noise & Vibration
Impacting sound pressure is 96.3 dB(A) and free speed sound pressure is 91.1 dB(A). Vibration level is 8.7 m/s².

Weight & Dimensions
The tool weighs 7.37 lb and measures 8.5 x 3.3 x 8.1 inches. Shipping weight is 9.2 lb.

Performance & Features
The 2145QiMAX is designed for demanding applications with a maximum reverse torque of 1,350 ft-lb. It features the durable TwinHammer mechanism, a steel hammercase, and a reverse-bias 7-vane motor. The ergonomic composite housing reduces operator fatigue, and a feather-touch trigger allows precise control. A 4-position power regulator and one-hand forward/reverse switch enhance usability. The tool includes a 360° swivel inlet and patented noise reduction technology.

Accessories
Available accessories include impact socket sets, extensions, hose whips, nipples, quick release couplings, filters, regulators, lubricators, and lubricant kits. Service kits for the impact mechanism and motor are also available.

Warranty
A two-year limited warranty is offered with tool registration.

Note
Product specifications are subject to change without notice.
