IMMA FBT MULTI-FUNCTION FLATBED SEMI-TRAILERS Model: FBT Series Multi-Purpose Flatbed Semi-Trailer Reinforced Body for Tropical, Desert and Arctic Conditions EEC Normed as per EU Norms Size (L x W): 12.400 x 2.550 mm (Up to L: 13.900mm) Chassis: l Heavy duty resisting steel with I crossed profile chassis ST52 A1 Class 6 mm roll-formed internal steel 2 or 3 units, Heavy Duty type Asbestos free brakes, Supported shock absorbers, Double tired 2” and 3,5” King Mile (42 Cr-4 Mo) as per SAE/DIN standards,

WABCO EBS, Landing Legs: 2 pcs x 24 tons Tires & Rims: 4+1 to 12+1 pcs all steel Phosphate coated sandblasted double layer epoxy interlined acrylic painted, as per RAL7037 grey color 24 V Electric installation as per EU norms, Accessories: l Rear bumper: Folding, pressed cage, made of ST-37 steel, Step tyre point IMMA FBT Semi-Trailers can be equipped as: o DRY GOOD: Steel patterned floor for dry good carriage CONTAINER: 8 x Container locks (2x20’ or 1x40’), ISO type TIMBER: Timber Apparatus: 2x6 pcs poles around the side, removable, 1.000 mm length, pole holes connected to strengthened side...

Courtesy Drawing of IMMA FBT-MP50/2
