IMADA Peel testing systems Ideal for adhesive tape, heat seal adhesives films, etc… ② Enabling an easy and accurate peel and adhesion test at an affordable price High frequency data capture at 2000 Hz, which assures an extremely accurate chart for peel strength analysis. Configuration - 90 degree peel test ⑥ ①Force gaugeZTS series (from 2N to 500N) ②Motorized test standMX2-500N-L (Recommended) ③CableCB-518 ④Graphic softwareForce Recorder Standard ⑤90 degree peel testing fixtureP90-200N ⑥Film gripFC series 90 degree peel test for adhesive tape Heat sealing 180 degree peel test Adhesive tape 180 degree peel test Fixtures ・P180-200N ・FC series It keeps peeling angle at 180 degree. Plastic foil lid from a cup container 45 degree peel test (2 pieces are used.) You can start peeling at 45 degree, nearly real conditions of opening it. Heat sealing part is pulled at 180 degree. * The specifications of test stand may have to be modified depending on test speed or specimens’ length. Enabling various peel tests by changing fixtures and grids Other products for peel test ・Rubber roller ◇180 degree peel tester (IPT200 series)◇ To bond a sample at a regular pressure It is exclusive for 180 degree peel test of emboss career tape’s cover film, adhesive tape, and so on, so its operation is very easy, which improves measurement efficiency. ・Plate for replacement To improve efficiency of measurement Please contact us to perform any test according to JIS or International standard. ○Visit our web page to learn more peel testing systems! IMADA Peel test ◇Corrugated Cardboard Adhesion Test◇ You can easily measure opening strength of bonded corrugated cardboard by handheld. http://www.forcegauge.net/ We are an expert of force measurement with 60-year history. Please feel free to contact us to find measurement solution and distributors in your country. Zip code: 441-8077 99 Jinnoshinden-cho aza Kanowari Toyohashi, JAPAN. Phone : 0532-33-3288 FAX : 0532-33-3866 E-mail : info@forcegauge.net
