Programme Survey 2010 Industrial Automation

Programme Survey 2010 Industrial Automation

Product catalog summary

Overview: This document provides comprehensive technical specifications and guidelines for various electrical connectors, inserts, enclosures, and cable management components. It covers material compositions, certifications, configurations, and installation procedures, ensuring compliance with international standards.

Specifications:

Inserts and Contacts: Made from UL recognized thermoplastic, self-extinguishing, compliant with EN 61984. Available in multiple configurations with silver-plated crimp contacts for cable sections from 0.14 mm² to 6 mm².
Enclosures and Housings: Designed for IP65, IP66, IP67, and IP69K protection, made from stainless steel and thermoplastic materials. Compatible with various inserts and available in different mounting options.
Cable Management Components: Includes cable glands, clamps, sealing plugs, and flexible tubes, offering protection levels of IP65 and IP68, with various threading options.

Procedures:

Crimping and Assembly: Detailed instructions for crimping contacts and assembling connectors using specific tools. Emphasizes the use of appropriate tools for optimal performance.
Installation: Guidelines for mounting inserts on frames, coupling protection covers with housings, and using gaskets for enhanced sealing.

Standards and Compliance:

Products comply with EN 61984, EN 60529, ANSI/UL 50, and other relevant standards, ensuring safety and performance under specified conditions.

Recommendations:

Use appropriate crimp contacts and tools for installation. Ensure correct insertion using guide rails to prevent incorrect coupling.
Consult ILME technical catalogues for detailed data sheets and additional information.

Key Data from Tables:

Cable Sections and Ratings: Detailed specifications for cable sections, pole numbers, and protection ratings for various components.
Product Variants: Lists different types of connectors, enclosures, and accessories, including part numbers and configurations.

Critical Information:

Voltage and Current Ratings: Inserts and connectors are rated for different voltage and current levels, with specific configurations for mixed rated currents.
Material Specifications: Emphasizes the use of self-extinguishing thermoplastic material for safety and compliance with international standards.

Additional Information: For further technical details and updates, users are directed to ILME's technical catalogues available on their website.
