Company Overview
INDUSTRIA LOMBARDA MATERIALE ELETTRICO SpA (ILME) has been a significant entity in the electrotechnical industry since 1938, with a focus on industrial installations. The company is globally recognized, particularly in automation-centric countries such as Germany and Japan, for its product innovation, customer service, and commitment to environmental sustainability.

CE Marking Compliance
Since January 1997, ILME has ensured that all its products carry the CE marking, in compliance with the Low Voltage Directive 73/23/CEE and its amendments. This marking indicates conformity with EU safety standards, with ILME products meeting both harmonized and international IEC standards.

Product Features: CSH Series
The CSH series "SQUICH" connectors are designed for tool-free connections, significantly reducing cabling time by 50% compared to traditional screw-type connections. These connectors feature spring terminals with actuator buttons for easy and reliable conductor connections, supporting wires with or without ferrules up to 2.5 mm².

Technical Specifications

• Operating temperature range: -40°C to +125°C
• Available sizes: "44.27", "57.27", "77.27", "104.27"
• Compatible with series CNE, CSE, CCE, CTE, CTSE, CN, CT, and CSS
• Rated current: 16A, Rated voltage: 500V
• Pollution degree: 2 or 3 depending on the configuration
• UL/CSA certification pending

Load Curves and Current Capacity
The current carrying capacity of connectors varies with the number of poles and ambient temperature. Load curves, constructed according to IEC 60512-5-2, provide guidance on the maximum permissible load. The correction curve ensures reliable operation within specified limits by accounting for safety margins.

Conclusion
ILME's CSH series connectors provide innovative, efficient, and reliable solutions for industrial applications, adhering to stringent safety and performance standards.
