The I.D.R.M. Company, founded in 1983, focuses on the design, manufacture, and marketing of equipment for hazardous, explosive, or corrosive environments. Their protective systems include pressurized apparatus, flameproof enclosures, increased safety, and intrinsic safety, complying with European standard EN 50.014 and ATEX directive 94/9/EC.
I.D.R.M. offers equipment for explosive and corrosive atmospheres, technical assistance, repairs, distribution of EEx products with CENELEC and U.L. approvals, training, spare parts, and technical documentation. The company is ISO 9001:2008 certified and ATEX notified by INERIS since 2002.
This directive governs equipment and protective systems for use in potentially explosive atmospheres, including safety, control, and regulating devices. It excludes medical devices, domestic equipment, personal protective equipment, and certain transport means.
ATEX classification differentiates between gas (G) and dust (D) atmospheres, with equipment protection levels categorized by presence type: continuous, intermittent, and episodic. Standards are outlined in EN/IEC codes for various protection methods.
Standards include EN 60079 series for gas atmospheres and EN 61241 for dust. Temperature classes range from T6 (85°C) to T1 (450°C), indicating maximum surface temperatures for safe operation.
Lists ignition temperatures for materials like maize, lignite, wheat, aluminum, polyethylene, sugar, charcoal, cocoa, and toner, with two temperature values for different conditions.
Outlines IP ratings according to IEC 529 and EN 60529 standards, describing protection levels against solids and water, from no protection to immersion.
Provides an example of CE marking, detailing manufacturer information, equipment type, construction number, year of manufacture, and specific markings.
Describes explosion-proof enclosures, including types PBX and PCX, with specifications like material, size, and protection ratings, and compliance with European directives.
Details on increased safety enclosures (BJX series), including dimensions, materials, and protection ratings, designed for explosive atmospheres.
References several European directives and standards, including ATEX 94/9/EC, EN 60079 series, and EN 50014.
Details technical specifications for various enclosure types, including certification numbers, marking, degree of protection, and material specifications.
Includes degree of protection, ambient temperature range, maximum voltage and intensity, and compliance with European directives and standards.
Outlines specifications for explosion-proof equipment, including pressurized enclosures, luminaires, emergency lighting, and floodlights, with details on electrical supply, material, ambient temperature range, zones, marking, and protection degree.
Includes details on pressurized enclosures, fluorescent luminaires, emergency lighting units, and floodlights, with additional features like optional glass windows and customizable options.
Technical specifications and compliance with European directives and standards for explosion-proof floodlights.
Technical specifications and compliance for explosion-proof lighting fixtures.
Technical specifications and compliance for explosion-proof indicating lights.
Technical specifications and compliance for explosion-proof traffic lights.
Technical specifications and compliance for explosion-proof enclosures for CCTV cameras.
Catalog excerpts
www.idrm.fr Tel : 33 (0)1 6061 5484 - Fax : 33 (0)1 6061 5477 I PRESENTATION DE LA SOCIETE / COMPANY PROFILE La Société I.D.R.M. a été créée en 1983. The I.D.R M. Company has been established in 1983. La Société I.D.R.M. est spécialisée dans la conception, la fabrication et la commercialisation de produits et d’équipements complets pour atmosphères dangereuses, explosives ou/et corrosives, avec les systèmes de protection suivants : - Surpression interne Ex p - Enveloppe antidéflagrante Ex d - Sécurité augmentée Ex e - Sécurité intrinsèque Ex i Tout en respectant les règles générales de la norme...
Open the catalog to page 2
www.idrm.fr Tel : 33 (0)1 6061 5484 - Fax : 33 (0)1 6061 5477 II SOMMAIRE // SUMMARY Page // Sheet TITRE // TITLE I Présentation de la société Company profile II Sommaire Summary III Rappel du chapitre 1, article 1er de la Directive Européenne (ATEX) N° 94/9/CE ou 100-A Reminder of chapter 1, article 1 of the European Directive (ATEX) N° 94/9/EC or 100-A IV, V Rappel des règles pour atmosphères explosibles Reminder of the rules for explosive atmospheres 1, 2 PBX Enveloppes antidéflagrantes Ex d IIB Explosion-Proof enclosures Ex d IIB 3, 4, 5, 6 PCX Enveloppes antidéflagrantes EEx d IIC Explosion-Proof...
Open the catalog to page 3
www.idrm.fr Tel : 33 (0)1 6061 5484 - Fax : 33 (0)1 6061 5477 III RAPPEL DU CHAPITRE 1, ARTICLE 1er de la DIRECTIVE EUROPEENNE (ATmosphères EXplosives) N° 94/9/CE ou 100-A REMINDER OF CHAPTER 1, ARTICLE 1 of the EUROPEAN DIRECTIVE (ATEX) N° 94/9/EC or 100-A Article premier 1. La présente directive s'applique aux appareils et aux systèmes de protection destinés à être utilisés en atmosphères explosibles. 2. Entrent également dans le champ d'application de la présente directive les dispositifs de sécurité, de contrôle et de réglage destinés à être utilisés en dehors d'atmosphères explosibles mais...
Open the catalog to page 4
www.idrm.fr Tel : 33 (0)1 6061 5484 - Fax : 33 (0)1 6061 5477 IV Rappel des règles pour atmosphères Explosibles Reminder of the rules for explosive atmospheres CLASSIFICATION ATEX ATEX CLASSIFICATION Atmosphères gaz / Gas atmospheres = G Atmosphères Poussière / Dust atmospheres = D ZONE Type d'atmosphère Type of atmosphere EPL Niveaux de protection du matériel Equipment protection levels Atmosphère Explosive Explosive atmosphere Catégorie des Appareils Equipment category 0 G Ga Présence Permanente Continuous presence 20 D Da 1 1 G Gb Présence Intermittente 21 D Db Intermittent presence 2 2 G...
Open the catalog to page 5
www.idrm.fr Tel : 33 (0)1 6061 5484 - Fax : 33 (0)1 6061 5477 V TEMPERATURES D'INFLAMMATION DES POUSSIERES DUST IGNITION TEMPERATURE Matières / Material Nuage / Cloud Couche de 5mm / 5mm layer Fibre de papier / Paper fiber 570 °C 335 °C Marc de café / Coffee grounds 580 °C 290 °C Maïs / Maize 530 °C 460 °C Lignite / Lignite 410 °C 270 °C Blé / Corn 510 °C 300 °C Aluminium 560 °C 430 °C Polyéthylène / Polyethylene 440 °C Fusion Sucre / Sugar 490 °C 480 °C Charbon de bois / Charcoal 520 °C 320 °C Cacao / Cocoa 590 °C 250 °C Toner 520 °C Fusion DEGRES DE PROTECTION DEGREES OF PROTECTION CEI/IEC...
Open the catalog to page 6
www.idrm.fr Tel : 33 (0)1 6061 5484 - Fax : 33 (0)1 6061 5477 - 1 - Enveloppes antidéflagrantes Explosion Proof enclosures II 2 GD / II 2(1) GD Ex d IIB T4, T5, T6 (IP66) Ex d [ia / ib] IIB T6 (IP66) Alliage d'aluminium pour ambiance marine Aluminium alloy for marine use Acier inoxydable (à la demande) Stainless steel (on request) Taille maximum : Maximum size : 705 x 505 x 385 mm EEx d IIB PBX
Open the catalog to page 7
www.idrm.fr Tel : 33 (0)1 6061 5484 - Fax : 33 (0)1 6061 5477 - 2 - Soucieux d’améliorer nos produits, nous nous réservons le droit de réviser, sans préavis, les caractéristiques de nos produits // Continuous developments may result in specifications changes without notice ENVELOPPES ANTIDEFLAGRANTES EXPLOSION-PROOF ENCLOSURES Ex d IIB T4, T5, T6 (IP66) Ex d [ia/ib] IIB T6 (IP66) TYPE : PBX-1, 2, 3, 3R, 4, 5 and 5R TYPE Reference Dimensions ext. Dimensions int. Fixations Platine de montage Mounting plate Poids Weight A B C a2 b2 c1 c2 e f Long. Larg. kg PBX-1 325 275 188 ~ 260 ~ 210 138 10 M8...
Open the catalog to page 8
www.idrm.fr Tel : 33 (0)1 6061 5484 - Fax : 33 (0)1 6061 5477 - 3 - Enveloppes antidéflagrantes Explosion Proof enclosures II 2 GD / II 2(1) GD EEx d IIC T5, T6 (IP65) EEx d [ia / ib] IIC T6 (IP65) Alliage d'aluminium pour ambiance marine Acier inoxydable (à la demande) Taille maximum : 300 x 300 x 200 mm Aluminium alloy for marine use Stainless steel (on request) Maximum size : 300 x 300 x 200 mm EEx d IIC PCX
Open the catalog to page 9
www.idrm.fr Tel : 33 (0)1 6061 5484 - Fax : 33 (0)1 6061 5477 - 4 - Soucieux d’améliorer nos produits, nous nous réservons le droit de réviser, sans préavis, les caractéristiques de nos produits // Continuous developments may result in specifications changes without notice ENVELOPPES ANTIDEFLAGRANTES EXPLOSION-PROOF ENCLOSURES EEx d IIC T5, T6 (IP65) EEx d [ia / ib] IIC T6 (IP65) TYPE : PCX-1, 2, 3, 4, 5. Puissances dissipées max. (Watt) Uniquement cas PCX-5 / Only case PCX-5 Maximum dissipated power (Watt) TYPE Dimensions Plaque de montage Mounting plate Poids Weight ( * ) ( ** ) A A1 B C C1...
Open the catalog to page 10
www.idrm.fr Tel : 33 (0)1 6061 5484 - Fax : 33 (0)1 6061 5477 - 5 - Enveloppes antidéflagrantes Explosion Proof enclosures II 2 GD / II 2(1) GD EEx d IIC T3, T4, T5, T6 EEx d [ia / ib] IIC T6 EEx d [ia] IIC T5 or T6 Alliage d'aluminium pour ambiance marine Aluminium alloy for marine use EEx d IIC PCX
