Terminal Blocks Switches & Pilot Lights Selection Guide Selection Guide Current Modular DIN Rail Terminal Blocks 901 10A to 150A Modular DIN Rail Fuse Holders 903 10A maximum One-Piece Power Blocks (DIN rail and surface mount) 905 200A to 350A 907 15A to 40A One-Piece DIN Rail Fuse Holders Signaling Lights Page One-Piece DIN Rail Terminal Blocks Relays & Sockets Appearance 908 10A maximum DIN Rail Break-Out Modules 917 1A maximum Key features of IDEC terminal blocks include: • Molded from UL94-V0 material with excellent flame- and shock-resistance • Mounts on a standard 35mm DIN rail •...

Terminal Blocks BNH/BN Key features: • Touch-down terminals with spring-loaded captive screws • Jumpers available up to 50A model • Fuse block with or without blown-fuse indicator in neon or LED • Mounts on 35mm standard DIN rail Signaling Lights UL Recognized File No. E78117 File No. R9551701 J9551516 (power blocks) R9650688 (dual-deck blocks) CSA Certified File No. LR64803 Relays & Sockets Specifications Model BNH10W Switches & Pilot Lights BNH/BN Series BNH15MW BNH15LW BNH30W Appearance 0.275” (7mm) 0.315” (8mm) 0.413” (10.5mm) 0.472” (12mm) Approvals UL, CSA, TUV UL, CSA, TUV UL, CSA,...

Terminal Blocks Signaling Lights Switches & Pilot Lights BNH/BN Specifications, continued Model BNH50W BN75W BN150W BNDH15W 0.610” (15.5mm) 0.787” (20mm) 1.024” (26mm) 0.315” (8mm) UL, CSA, TUV UL, CSA, TUV UL, CSA, TUV UL, CSA, TUV Appearance Width Approvals No. of Poles 1 1 1 2 Wire Sizes 16 to 6 AWG 16 to 4 AWG 16 to 0 AWG 22 to 14 AWG 600V / 10A Voltage/Current Relays & Sockets Terminals 600V / 50A 600V / 75A 600V / 150A Size M5 M6 M8 M3 Type Touch-down Hex bolt Hex bolt Touch-down 35mm DIN rail 35mm DIN rail 35mm DIN rail 35mm DIN rail, surface 2.6 - 3.7 3.9 - 5.4 10 - 13.5 0.6 - 1.0...

Terminal Blocks BNF Fuse Blocks Model BNF10SW BNF10NW BNF10DW 0.591” (15mm) 0.591” (15mm) 0.591” (15mm) None Neon (100–300VAC) LED (24V DC) UL, CSA UL, CSA Switches & Pilot Lights Specifications, continued UL, CSA Appearance Blown Fuse Indicator Approvals No. of Poles 1 1 1 Wire Sizes 18 to 10 AWG 18 to 10 AWG Signaling Lights Width 18 to 10 AWG Voltage/Current 600V/10A maximum 600V/10A maximum M4 M4 M4 Type Standard screw Standard screw Standard screw 35mm DIN rail 35mm DIN rail 35mm DIN rail Mounting (N-m) 1.4 - 2.0 1.4 - 2.0 1.4 - 2.0 (in-lbs.) 12.4 - 17.8 12.4 - 17.8 12.4 - 17.8 End...

Terminal Blocks BN Power Blocks Switches & Pilot Lights BN Power Block Series Key features: • Up to 350A are available for DIN rail or direct mounting on panel surfaces • 2, 3, 4 pole models available CSA Certified File No. LR64803 Signaling Lights UL Recognized File No. E78117 File No. J9551516 Specifications BN400NW# (replace # with the number of poles) BN200NW#K (replace # with the number of poles) BN400NW#K (replace # with the number of poles) See dimension table on page 906 See dimension table on page 906 See dimension table on page 906 See dimension table on page 906 UL, CSA, TUV UL,...

Terminal Blocks BA Series Switches & Pilot Lights BA Series Key features: • Self-contained: end plates are not required • Rugged heavy-duty construction • Current capacities up to 40A • 3-pole units available as 1 piece (no endplates are needed) • Fuse blocks with blown fuse indicators Signaling Lights UL Recognized File No. E78117 CSA Certified File No. LR64803 Specifications Relays & Sockets Power Blocks Model BA111T BA211T BA311T BA411S 0.984” (25mm) 1.201” (30.5mm) 1.358” (34.5mm) 0.630” (16mm) UL, CSA UL, CSA UL, CSA UL, CSA 3 3 3 1 16 to 6 AWG Appearance Approvals No. of Poles Wire...

Terminal Blocks Switches & Pilot Lights BA Series Specifications, continued Fuse Blocks Model BAF111SU BAF111SNU BAF111SDU 0.630” (16mm) 0.630” (16mm) 0.630” (16mm) None Neon (100 to 300V AC) LED (24V DC) UL, CSA UL, CSA UL, CSA 1 1 1 Signaling Lights Appearance Width Blown Fuse Indicator Approvals No. of Poles Relays & Sockets Wire Sizes 18 to 10 AWG 18 to 10 AWG 18 to 10 AWG Current 10A maximum 10A maximum 10A maximum Size M4 M4 M4 Type Standard screw Standard screw Standard screw 35mm DIN rail 35mm DIN rail 35mm DIN rail Terminals Mounting Terminal Torque (N-m) 1.4 - 2.0 1.4 - 2.0 1.4 -...

Terminal Blocks BA Series Part No. Diagrams 7.9 7.9 6.7 Dust Cover 2 38.5 20.0 Dust Cover ø3.6 min. 8.4 max. 20.0 4 min. 50 Dust Cover Relays & Sockets 13 5 max. 2 16 ø4.2 min. When using BAA/BAP: 37.5 2-M5 Screw 3.3 min. 38.5 8.5 2 9.8 When using BAA/BAP: 32 6-M3.5 Screw 30.5 9.8 5 max. Signaling Lights BA211T ø3.2 min. 6.6 max. When using BAA/BAP: 32 6-M3 Screw 25 BA111T Switches & Pilot Lights Dimensions 22.8 BA311T 9.4 max. 6 max. 4.5 min. 48 2 13 50 Dust Cover ø5.2 min. 22.8 BA411S Timers When using BAA/BAP: 37.5 2-M5 Screw 16 12.8 max. 6.5 max. 4.5 min. 48 63 36 ø4.2 min. When using...

Terminal Blocks Switches & Pilot Lights Accessories Accessories Part Numbers: End Plates, DIN Rail Stops, Stand-Offs, DIN Rail and Dust Covers Item Appearance Use with Part No. Remarks BNH10W BNH15MW BNE15W BNH15LW BNH30W BNE30W Signaling Lights BNF10SW End Plates BNF10NW BNE20 BNF10DW BNH50W BNE50W BN75W BNE75W BN150W BNE150W BNDH15W BNDE15W BNH10W Relays & Sockets BNH15MW BNH15LW BNH30W BNH50W BNF10SW BNF10NW BNL5 (small) 1. DIN rail stops prevent side-to-side movement. 2. The BNL-5 width is 0.375” (9mm). BN75W BN150W BNL6 (medium) 1. DIN rail stops prevent side-to-side movement. 2. The...

Terminal Blocks Accessories Switches & Pilot Lights Accessories, continued Part Numbers: Rods, Nuts, Marking Strips, Dust Covers, and Jumpers Item Appearance Use with Part No. Remarks BNDH15W BNH10W BNH15MW BNC230 BNH15LW BNH30W BNH50W BNC320 BN75W BNC420 BN150W BNC520 BN200 BAC820 BN400 The overall length is 39.37” (1,000mm). The material is polycarbonate (UL94-V2). BNC1000 BNM7 Material: fiberglass Strip dimensions are 0.37”x39” (9.5 x 1,000mm). BNM3 Used to prevent marking strips from sliding off terminal block. All series All series BNJ46 BNJ56 BNJ26W BNJ62 BNH10W BNJ16F BNH15MW BNJ26FW...
