Complete Display Lights Catalog

Complete Display Lights Catalog

Product catalog summary

Overview: This document provides comprehensive details on IDEC's product offerings, focusing on automation and sensing, safety, switching and controls, and display lights. It includes specifications, features, and part numbers for various products, particularly the SignaLight Towers.

Key Sections:

Automation & Sensing: This section covers products related to automation technologies and sensing devices.
Safety: This section includes safety-related products and standards.
Switching & Controls: Information on switches, pilot lights, relays, sockets, timers, terminal blocks, and circuit breakers is provided.
Display Lights: Includes selection guides and specifications for SignaLight Towers, focusing on the LT7 and LT1 series.

Display Lights - SignaLight Towers:

LT7 Series: Features ultra-bright LEDs, modular assembly, and IP65 protection. Available in various colors and configurations, with options for alarms and flashing functions.
LT1 Series: Offers customizable configurations with LED or incandescent lamps. Known for long service life and vibration resistance, suitable for indoor use with IP20 protection.

Specifications:

LT7 Series: Details on voltage, power consumption, alarm sound levels, and environmental protection ratings.
LT1 Series: Specifications for different lamp types, voltage ratings, and mounting options.

Part Numbers and Assembly: The document includes detailed part numbers for both assembled and sub-assembled units, allowing for easy identification and ordering of specific configurations.

Additional Resources: References additional resources available online, such as product information, software demos, manuals, and training schedules.

SLC40 Series Panel Mounted Annunciators:

Designed for simplifying panel cutouts with various window sizes.
Available with incandescent or Superbright LED illumination, customizable with up to 105 windows.
Features non-reflective clear lenses and supports a wide variety of input voltages.

Key Features:

Custom configurations with up to 105 windows.
Four window sizes based on a 40mm grid.
Non-reflective clear lenses.
Incandescent or Superbright LED illumination.
Wide variety of input voltages.

Certifications:

UL Recognized
CSA Certified
ABS Certified

Specifications:

Light Source: LED or Incandescent
Nominal Voltages: 6, 12, 24V AC/DC; Transformer: 120, 240V AC; DC-DC Converter: 110V DC
Colors: Amber, Green, Red, Yellow, Blue (24V only), White, dual color Red/Green (24V only)
Insulation Resistance: 100MW minimum
Degree of Protection: IP20, NEMA 1
Operating Temperature: –20˚ to +40˚C

Part Number Guide: The part number is structured based on the number of rows, columns, type, voltage, style, and color of windows.

Dimensions: Panel cut-out dimensions vary based on the number of rows and columns, with specific measurements provided for different window styles.

Engraving Information: Engraving plates are available for different window types and sizes, with specifications for character size and maximum characters per line.

Engraving Methods: Two methods are provided for engraving SLC annunciator layouts, ensuring clarity and consistency in the final engraved panel.

Accessories: Various accessories are listed, including lenses, color screens, marking plates, and lens frames, each with specific part numbers and applications.

Installation Instructions: Guidelines are provided for installing SLC series units, emphasizing the importance of ventilation, panel thickness, and proper wiring.

Mounting Clips: Details the number and recommended positions of mounting clips based on the number of columns and rows in the SLC layout.

Assembly Order for Lamp Colors: Instructions are given for assembling lamps with different on/off colors, ensuring the correct visual output for various applications.
