Selection Guide IDEC YS Series Contactors / Starters IDEC YS Series Contactors are used in switching motor loads. Like allIDEC products, each model is engineered for long life, minimum mainte- nance, dependable operation, and superior performance.Snap on accessories are available for the IDEC YS series, giving eachmodel the flexibility to meet any application requirement.1. Auxiliary contact blocks 2. Adjustable thermal overloads 3. Surge suppressor modules 4. Mechanical interlock blocks 5. PLC interface modules Top mounting type (2 or 4 poles type) ՕSide mounting type (2 poles type) > IEC Contactors...

(With Surge Suppressor Module)YS9Z-TCU500UH > The interface module incorporates con-tacts which are actuated upon energiza- tion of the module from low power 24VDC sources such as outputs from sensors and programmable controllers. for YS1N-80F to -125FYS9Z-TU180 for YS1N-150F to -180FYS9Z-TU300 for YS1N-220F to -300F For reversing applicationsYS1R, AC Controlled YS3R, DC Controlled(reversing type) Used for reversing contactorsYS9Z-TMI65 for YS1N-9F through 65F YS9Z-TMI125 for YS1N-80F through 300F > IEC Contactors

Completed Part Number of Contactors1 Product Series YS1N: Non- reversing contactor, AC controlled YS1R: Reversing contactor, AC controlled YS3N: Non-reversing contactor, DC controlled YS3R: Reversing contactor, DC controlled4 Coil Voltage 2 a) Approximate Maximum AC3 Current AC or DC Controlled Contactors D024 : DC 24V 9:9A, 12:12A, 20:20A, 25:25A, 32:32A, 38:38A, 40:40A, 50:50A, 65:65A, 80:80A, 100:100A, 125:125A AC Contactors Only 150:150A, 180:180A, 220:220A, 300:300A (Other Voltages Available, Contact IDEC)A600 : AC600V 50/60HzD110 : DC 110VD220 : DC 220V M100 : DC 110V M200 : DC 220VD048...

Notes: 1. Use the above ordering information only when interpreting part numbers. Do not use for developing part numbers. 2. For applicable combinations of contactors and thermal overload relays, please consult following page. 3. For specifications and settings please see pages D-16 through D-34. >

Completed Part Number of Reversing Starter1 Product Series YS2N AC non-reversing StarterYS1R contactor ----> YS2R AC reversing StarterYS3N contactor ----> > IEC Contactors YS4N DC non-reversing StarterYS3R contactor ----> YS4R DC reversing Starter F: is replaced by size, 9-300 for AC controlled FG2: is replaced by size, 9-65 for DC controlled FG: is replaced by size, 80-125 for DC controlled 01: with 1NC, for contactor sizes 9F-12F 10: with 1NO, for contactor sizes 9F-12F 11: with 1NO-1NC, for contactor sizes 20F-65F 22: with 2NO-2NC, for contactor sizes 80F-300F YS1N contactor ----> 5 Coil Voltage...

Accessory Description Part Number > each part number is for ONE (1) main contact Stationary Main Contacts > For use with YS-20FYS9Z-KIF409056-AFor use with YS-25FYS9Z-KIF409057-A For use with YS-32FYS9Z-KIF410179-A For use with YS-38FYS9Z-KIF410180-A For use with YS-40FYS9Z-KIF409083-A For use with YS-50FYS9Z-KIF409083-B For use with YS-65FYS9Z-KIF409083-C For use with YS-80FYS9Z-KIF410697-A For use with YS-100FYS9Z-KIF410697-B For use with YS-125FYS9Z-KIF410697-C For use with YS-150FYS9Z-KIF410853-A For use with YS-180FYS9Z-KIF410854-A For use with YS-220FYS9Z-KIF411841-A For use with YS-300FYS9Z-KIF411842-A...

Part Number Description For Use WithBAA1000 > 35mm Aluminum DIN Rail 7.5 mm deep1 meter longYS1N-9F through YS1N-38F Contactors BNDN1000 > 35mm Aluminum DIN Rail 10.5 mm deep. 1 meter longYS1N-9F through YS1N-38F Contactors IEC Contactors YS9Z-TIP66 Markers > Plastic replacement markerssold in 100 piece packsYS-9F through YS-65F series contactors, overloads relays and top mount auxiliary contact blocks. BNL8 > DIN Rail End Stop used to prevent contactors from sliding on DIN rails YS1N-32F/YS1N-38F & YS1R reversing contactors BNL5 > DIN Rail End Stop used to prevent contactors from sliding on...

Ambient Temperature > -5 to +40аC Temperature inside the control panel > -5to +55аC Relative humidity > 45% to 85% RH Altitude > No more than 2,000m Vibration resistance > 10 to 50Hz 19.6m/s 2 ( 2G ) Shock resistance > 49.0m/s 2 (5G) Storage temperature > -40C to +70аC 30 30 а 30 Direct Mounting 1. Install the product in a dry area with minimal dust and vibration.2. Standard mounting is done on a vertical surface in the directions shown in Figure 1. However, a mounting angle up to 30 degrees is allowed in each direction as shown in Fig- ure 2. Operational characteristics of the product, when...

Top Mount Style Removal Procedure Side-Mount StyleDIN rail Mounting Removal Procedure 1. Position the contactor and the auxiliary contact block in thesame direction.2. Insert the auxiliary contact block into the area of the top ofthe contactor. Slide the auxiliary contact until it bottoms (Do not force.) Make sure that the locking hook is locked into posi- tion as shown While lightly lifting the locking hook with your finger, slide theauxiliary contact unit out. 1. Contactor plunger2. Inside this area, there are locking hooks (upper and lower areas)1. Make sure that the auxiliary contact block...

Mounting Procedure (YS9Z-TMI65) Removal ProcedureMounting Procedure (YS9Z-TMI125) Removal Procedure 1. Position the mechanical interlock block and the contactor in the same direction. (Thename plate of the mechanical interlock block should be in the same direction as the name plate of the contactor.2. Insert the connection pins of the mechanical interlock block (located on the left andright sides of the mechanical interlock block) into the pin holes of the forward and reverse contactors (the forward contactor in the right and the reverse contactor in the left in the picture). Carefully push the...

2-4.8 DIA. MTG HOLES(M4) 2-4.8 DIA. MTG HOLES(M4) 2-4.8 DIA.MTG HOLES(M4) 2-4.8 DIA. MTG HOLES(M4) DIN RAIL 75mm 2-4.8 DIA.MTG HOLES(M4) > 15.5 DIN RAIL 35mm > 6 AB B 52 95100 34535 4.5 > IEC Contactors A 7655 >

MaximumOperationalCurrent AC1 Instantaneous Auxiliary Contacts Category AC1(Star Connection) Completed Part Number 220V 230V 380V 400V 415V 440V 500V 660V 690V NO NCkWkWkWkWkWkWA > IEC Contactors
