Introduction to Fiber Laser Technology
Fiber laser technology offers solid-state simplicity, efficiency, and reliability. HyIntensity Fiber Laser systems utilize a low-maintenance solid-state laser source, delivering the laser beam through a fiber optic cable to the laser head. This technology is more energy-efficient and flexible compared to CO2 lasers, making it a cost-effective solution for metal cutting without the need for mirrors or lasing gas.

Hypertherm's Expertise
With over 40 years of experience in high-temperature metal cutting, Hypertherm has developed over 75 patented thermal cutting technologies. Their extensive global OEM base and cutting-process focused research enable them to provide industry-leading performance and make fiber laser technology accessible to the steel fabricating market.

HyIntensity Fiber Laser HFL015
The HFL015 is a fully optimized cutting system designed for consistent laser quality across various materials and thicknesses. It features a 1.5 kW fiber laser supply with a cutting capacity of up to 12 mm mild steel. The system is designed for ease of operation, integration, and automatic cutting process optimization. It includes pre-set cutting parameters and allows for easy process changeover.

Applications and Advantages
HyIntensity Fiber Laser systems are easily integrated into various cutting machines and offer superior cut quality and tolerances for fine-feature cutting. They provide higher cut speeds and lower operating costs compared to CO2 or plasma on material thicknesses below 6 mm. The technology can be combined with plasma for enhanced productivity and quality.

Specifications and Safety
The system operates at 400-480 VAC, 50/60 Hz, with a duty cycle of 100% at 40°C. It meets safety standards such as IEC#: EN ISO 13849-1 PL:e+ and includes safety features like external E-stop and door interlock switches. The system dimensions are 147 cm (H) x 82 cm (W) x 93 cm (L), weighing 226 kg. It supports various gas supplies and has a nominal output power of 1500 W.

Performance and Warranty
Hypertherm offers a full-system warranty with two years of coverage on all components and one year on the laser head and beam delivery optics. The system is ISO 9001:2000 certified, ensuring quality and reliability.
