Product catalog summary

Overview: The document outlines the specifications and features of worm gearboxes, particularly the Nema-Inch Range, designed for right-angle gear applications. These gearboxes are vent-free and oil-free, ensuring no leakage and lifetime lubrication with synthetic, semi-fluid gear lubricant.

Key Features:

Vent-Free Design: No breathers or vents, factory lubricated for life, operating between -15ºC to 130ºC.
Modular and Compact: Complies with IEC standards, featuring a compact integrated motor and NEMA C flange.
Output Shaft Options: Available in hollow, single, and double solid configurations.
High-Temperature Seals: Equipped with Premium Nitrile® output seals for enhanced durability.
Single-Piece Housing: Constructed from aluminum alloy, vacuum impregnated, and precision machined.
High Helix Angle Worm: Case-hardened and ground for noise reduction and efficiency.
Oversized Bearings: Designed for higher shock load capacity, suitable for frequent starting and reversing.
Bronze Alloy Worm Gears: Centrifugally cast onto an iron hub for strength and longevity.

Selection and Specifications:

Selection Guide: Covers mounting positions, lubrication, radial and axial loads, reversibility, thermal limits, and ATEX certification.
Accessories: Includes various mounting accessories and options for interchangeability.
Installation and Maintenance: Provides guidelines for installation, use, and maintenance, along with a spare parts list.

Technical Data:

Types and Sizes: Specifications for types 045, 050, 063, and 085, including output torque and motor power.
Lubrication: Recommended oil quantities and types for different gearbox sizes.
Radial and Axial Loads: Tables for permissible loads on the gearbox.

Ordering Information: Instructions on selecting and ordering the appropriate gearbox, considering motor flange availability and mounting options.

Specifications:

Axial Loads: Strong axial loads in the DX direction are not permitted for the output shaft.
Lubrication: Units come with synthetic oil for long-life lubrication, with specific oil types and quantities recommended.
Motor Flanges: Various positions available, with options for reduction bushings upon request.

Procedures:

For mounting positions V5-V6, contact technical support for guidance.
Refer to tables for permissible radial and axial loads.

Norms and Recommendations:

Ensure power does not exceed the gearbox's maximum, selecting based on torque M2R.
Consult the website for complete technical data and documentation.

Key Data from Tables:

Dynamic Efficiency: Ranges from 60% to 88% across models.
Output Torque and Speed: Detailed with specific ratios and service factors for different configurations.
Lubrication Quantities: Specified in ounces for different models.

Additional Features:

Special hollow shafts and double extended worm shafts available on request.
Quick selection guides provided for ease of choosing the appropriate model.

Catalog excerpts

Worm gearboxes Riduttori a vite senza fine Rightangle Gears Nema-Inch Range Cat.: CT-VFP-BS-HM010

Open the catalog to page 1

vent free Vent Free Design. oil free No breather or vents to leak! Factory lubricated for life with synthetic, semifluid gear lubricant with an operating range of -15ºC to 130ºC. World wide sales network. A modular and compact product Flange Fully modular to IEC and compact integrated motor. NEMA C flange. Standard hollow output shaft mounting Reduces total drive envelope size, weight and cost. Single and double solid output shaft is available. Premium, high temperature Nitrile® output seals Single-piece aluminum alloy housing Is vacuum impregnated (MIL-STD 276) for protection and sealing. No...

Open the catalog to page 2

Features Selection Selection guide - fs Guida alla selezione Mounting pos. - Lubrication Pos. di montaggio - lubrificazione 2 - 6 poles selection Selezione 2 - 6 poli Radial - axial loads Carichi radiali e assiali Reversibility Reversibilità Thermal limit Limite termico Atex certification Certificazione Atex Accessories Accessori Download 3D drawings Download disegni 3D Interchangeability Intercambiabilità Installation and maintenance Installazione, uso e manutenzione Spare parts list Liste parti di ricambio For : / Per : / Para : 2-11 2-12 2-13 2-14 On page / A pagina / En la página Types /...

Open the catalog to page 3

-F P 045 PA 10 U S W R B M P 045 050 063 085 M P See technical data table tecnici. Ver tabla datos técnicos Vedi tabelle dati Output flange diameter Diametro flangia uscita 411A 511A ø 0.875 Y ø 1.125 W Output shaft diameter Diametro albero uscita ø ø X ø 0.625 U 2 X Y W ø NEMA 182/4TC 143/5TC 56C With Flange for type P Type - Tipo Typ 050 063 045 ø0.750 ø1.000 ø1.125 211A (metric) 411A ø143/5TC ø71 B14 050 063 085 045 P 311A -F 2.84 X S W 211A 411A 511A R BR FB PB PA PV F1 F2 F3 FC FL F4 A pedido, se pueden enviar nuestros productos de acuerdo con las normas ATEX. A richiesta possiamo fornire...

Open the catalog to page 4

1.29 0.91 0.67 257 257 257 QUICK SELECTION / Selezione veloce 80 79 77 2.2 2.2 2.4 01 02 03 RD Ratios Mn code input speed (n ) = 1750 min-1 1 Dynamic efficiency Tooth Module 250.0 175.0 125.0 7 10 14 1 0.75 0.75 202 213 291 1.3 1.2 0.9 n[min2 -1] i P1M [HP] M2M [lb in] f.s. P1R [HP] M2R [lb in] Output Speed Ratio Motor power Output torque Service factor Nominal power Nominal torque 56C - Available NEMA motor flanges W - 345lb in Rightangle - Gear 2-2 Velocità in entrata Input speed Velocidad de entrada A Select required torque (according to service factor) Seleccionar el par deseado (incluyendo...

Open the catalog to page 5

RADIAL AND AXIAL LOADS Output shaft Albero di uscita *Strong axial loads in the DX direction are not allowed. Non sono consentiti forti carichi assiali con direzione DX Input shaft albero in entrata AGIP KLUBER SHELL ESSO Telium VSF 320 Klubersynth EG4-320 Omala Hd320 Spartan Synt. Ep320 LUBRICATION 045 Oil Quantity 3.17 ounces tab. 1 47 FR [lb] FA [lb] 9 n [min ] 1750 1 -1 FR [lb] FA [lb] n [min ] 2 -1 40 225 247 270 315 405 450 202 45 49 54 58 67 90 200 150 100 75 50 25 15 tab. 2 345lb in Rightangle - Gear FA (lb) FR (lb) SX DX * F ( ) A (lb) FR (lb) C) * Power higher than the maximum one which...

Open the catalog to page 6

Output shaft Albero di uscita *Strong axial loads in the DX direction are not allowed. Non sono consentiti forti carichi assiali con direzione DX Input shaft albero in entrata RADIAL AND AXIAL LOADS AGIP Telium VSF 320 LUBRICATION 050 Oil Quantity 6.35 ounces tab. 1 85 FR [lb] FA [lb] 17 n [min ] 1750 1 -1 FR [lb] FA [lb] n [min ] 2 -1 54 315 337 382 427 562 629 270 63 67 76 85 108 126 200 150 100 75 50 25 15 tab. 2 611lb in Rightangle - Gear SX DX * F ( ) A (lb) FR (lb) FA (lb) FR (lb) KLUBER SHELL ESSO Klubersynth EG4-320 Omala Hd320 Spartan Synt. Ep320 Motor Flange Holes Position Posizione...

Open the catalog to page 8

LUBRICATION 063 Oil Quantity 14.11 ounces Output shaft Albero di uscita *Strong axial loads in the DX direction are not allowed. Non sono consentiti forti carichi assiali con direzione DX RADIAL AND AXIAL LOADS tab. 1 tab. 2 1240lb in Rightangle - Gear FR [lb] FA [lb] n [min ] 2 -1 101 FR [lb] FA [lb] 20 n [min ] 1750 1 -1 81 450 517 562 674.5 854 899 404.5 90 103.5 112.5 135 157 180 200 150 100 75 50 25 15 Input shaft albero in entrata SX DX * F ( ) A (lb) FR (lb) FA (lb) FR (lb) AGIP Telium VSF 320 KLUBER SHELL ESSO Klubersynth EG4-320 Omala Hd320 Spartan Synt. Ep320 Motor Flange Holes Position...

Open the catalog to page 10

n [min ] LUBRICATION 085 Oil Quantity 42.33 ounces RADIAL AND AXIAL LOADS Output shaft Albero di uscita *Strong axial loads in the DX direction are not allowed. Non sono consentiti forti carichi assiali con direzione DX FR [lb] FA [lb] n [min ] 2 -1 182 FR [lb] FA [lb] 1750 36 1 -1 tab. 1 tab. 2 112 652 674 787 899 1124 1304 562 130 135 157 180 225 261 200 150 100 75 50 25 15 2921lb in Rightangle - Gear Input shaft albero in entrata SX DX * F ( ) A (lb) FR (lb) FA (lb) FR (lb) AGIP Telium VSF 320 KLUBER SHELL ESSO Klubersynth EG4-320 Omala Hd320 Spartan Synt. Ep320 Motor Flange Holes Position...

Open the catalog to page 12

045 + 211A Basic wormbox Riduttore base Lubrification Oil quantity 2.05 2.35 2.80 3.38 4.70 standard 6.22 8.29 9.83 (56C) kit cod. KU050.4.041 (PAM 71B14) kit cod. K050.4.045 AGIP KLUBER SHELL ESSO Telium VSF 320 Klubersynth EG4-320 Omala Hd320 Spartan Synt. Ep320 tab. 1 C) * Power higher than the maximum one which can be supported by the gearbox. Select according to the torque M2R Potenza superiore a quella massima sopportabile dal riduttore. Selezionare in base al momento torcente M2R B) B) QUICK SELECTION / Selezione veloce 74 72 60 57 53 49 47 45 40 36 2.2 2.2 2.4 1.6 2.5 1.8 1.5 1.2 1.0...

Open the catalog to page 14

050 + 211A Basic wormbox Riduttore base B) B) C) QUICK SELECTION / Selezione veloce 76 75 69 61 61 56 49 47 44 40 36 2.5 2.4 2.6 2.0 2.7 2.1 1.8 1.3 1.2 1 0.8 01 02 03 04 05 06 07 08 09 10 11 RD Ratios Mn [mm] code input speed (n ) = 1750 min-1 1 Dynamic efficiency Tooth Module Motor Flange Holes Position Posizione Fori Flangia Motore Available on Request without reduction bushing Disponibile a Richiesta senza Bussola di Riduzione Supplied with Reduction Bushing Fornito con Bussola di Riduzione Motor Flanges Available Flange Motore Disponibili 53.2 37.2 26.6 20.7 14.3 10.3 8.7 6.2 5.5 4.7 3.7...

Open the catalog to page 15
