Argweld® Quick Purge™ Pipe Purging Systems (Power Point Presentation)
24Pages

ARGWELD® Product Presentation Quick Purge™ Pipe Purging Systems

USING PROVISIONAL DAM SYSTEMS Provisional Dam Systems ¡ Time consuming to fabricate ¡ Full of voids, gas and water vapour ¡ Made with high vapour pressure materials May leak and allow harmful gases back into the welding environment. ARGWELD® RANGE 2

USING PROVISIONAL DAM SYSTEMS Provisional Dam Systems ¡ Full of voids, gas and water vapour May leak and allow harmful gases back into the welding environment. ARGWELD® RANGE 2

USING PROVISIONAL DAM SYSTEMS Provisional Dam Systems May leak and allow harmful gases back into the welding environment. ARGWELD® RANGE 2

Uses less inert gas Faster Quick and easy to install, dams inflate instantly, purging time is fraction of time required for conventional methods Improved weld quality Leading to bright, shiny, coke and oxide-free welds Fast payback Argweld® Inflatable pipe purging systems pay for themselves in just one or two welds Highest standards Manufactured to nuclear quality with nuclear approved materials Quick Purge™ Inflatable Pipe Purging Systems ARGWELD® RANGE 3 Patented collar system provides full quality purge with only a tiny percentage of the gas required by any other purging method.

All manufactured from materials which do not contain contamination and do not outgas any harmful materials into the weld zone Quick Purge™ System Quick Purge™ Systems ARGWELD® RANGE 4

Quick Purge™ Systems ARGWELD® RANGE 5 Luminous centre guide strip for easy view inside dark pipes

affddd Quick Purge™ Systems ARGWELD® RANGE 5 We also manufacture large ones: 78” diameter model

Deflated AQP system being moved into pipe for weld purging ARGWELD® RANGE 6 Quick Purge™ Systems – Schematic 1

Inflated AQP system schematic showing Argon flow in, purging the air out. ARGWELD® RANGE 7 Quick Purge™ Systems – Schematic 2

Argon has displaced all air and Argweld® Purge monitor will show lower than 0.1% at this point ARGWELD® RANGE 8 Quick Purge™ Systems – Schematic 3

On site instruction for welders and technicians in Thailand ARGWELD® RANGE 9 Quick Purge™ Systems

ARGWELD® RANGE 10 Quick Purge™ Systems Inser9ng Quick Purge™ into pipe

ARGWELD® RANGE 11 Quick Purge™ Systems Inser9ng Quick Purge™ into pipe 2

ARGWELD® RANGE Quick Purge™ Systems In house Distributor Training Course 12

ARGWELD® RANGE Quick Purge™ Systems Pipe Purging System connected to Argweld® Weld Purge Monitor 13

Quick Purge™ Inflatable Purge Systems ¡ Re-usable ¡ Range 8 – 80” (200 mm – 2 M over and over again ¡ Saves time & gas consumption ¡ Dramatically reduces purging times ¡ Cost-effective ¡ Resistant to weld heat ARGWELD® RANGE permatypeco@snet.net

ARGWELD® RANGE Argweld® Quick Purge™ Systems ¡ Developed specifically for high speed welding of LNG pipework and pipe lines. ¡ Also suitable for large pipes, tanks and vessels. ¡ Inside is covered with heat protective materials, for protection of the device. ¡ Sizes from 8” to 80” (200mm - 20000mm). ¡ Very fast weld purge time and a very high quality weld root. 7 Cost comparison Quick-Purge Systems and Pre-Formed Paper Dams 18” Pipe Pre-Formed Water Soluble Paper Purge Dams: ¡ Average selling price is £Jon to insert for a package of 24 ¡ 2 dams per weld = 12 welds per package Quick-Purge™:...

ARGWELD® RANGE Argweld® Quick Purge™ Systems ¡ Developed specifically for high speed welding of LNG pipework and pipe lines. ¡ Also suitable for large pipes, tanks and vessels. ¡ Inside is covered with heat protective materials, for protection of the device. ¡ Sizes from 8” to 80” (200mm - 20000mm). ¡ Very fast weld purge time and a very high quality weld root. 7 Cost comparison Quick-Purge Systems and Pre-Formed Paper Dams 24” Pipe Pre-Formed Water Soluble Paper Purge Dams: ¡ Average retail price is £**** Jon for a package of 24 ¡ 2 dams per weld = 12 welds ¡ £***** Jon / 12 welds = £*****...

ARGWELD® RANGE Argweld® Quick Purge™ Systems ¡ Developed specifically for high speed welding of LNG pipework and pipe lines. ¡ Also suitable for large pipes, tanks and vessels. ¡ Inside is covered with heat protective materials, for protection of the device. ¡ Sizes from 8” to 80” (200mm - 20000mm). ¡ Very fast weld purge time and a very high quality weld root. 7 Cost comparison Quick-Purge Systems and Pre-Formed Paper Dams ARGWELD® RANGE 15

Sponge foam plugs vs Argweld® Quick Purge™ (Efficiency analysis) A. Sponge Foam Plugs setting & purging time B. TIG welding time; stainless steel pipe, 3 pass welding C. Total working (setting, purging and welding time) D. Sponge System purging gas flow (approx. 3.5 times more than Quick Purge ) Pipe O.D. A. Setting & Purging B TIG Welding Time C=A+B Total working D. Ar Gas Flow E. total Ar Gas flow E=C+D F. Ar gas Cost G1). Ar gas total cost (inch) (min) (min) (min) (L / min) (L / pcs) £/lit £ 1 16” 10 120 130 24 3120 0.23 718 2 20” 12 150 162 24 3888 0.23 894 3 25” 14 187.5 201.5 24 4836...

Argweld® Quick Purge™ Systems (Efficiency analysis) Pipe O.D. A. Setting & Purging B TIG Welding Time C=A+B Total working D. Ar Gas Flow E. total Ar Gas flow E=C+D F. Ar gas Cost G1). Ar gas total cost (inch) (min) (min) (min) (L / min) (L / pcs) (£/lit) £ 1 16” 3 120 123 7 861 0.23 198 2 20” 4 150 154 7 1078 0.23 248 3 25” 5 187.5 192.5 7 1347.5 0.23 310 4 27” 5 202.5 207.5 7 1452.5 0.23 334 5 45” 7 337.5 344.5 7 2411.5 0.23 555 6 50” 7 375 382 7 2674 0.23 615 7 60” 8 450 458 7 3206 0.23 737 A. Argweld® Quick Purge™ System setting & purging time B. TIG welding time; Stainless Steel pipe, 3...
