PID01 electrically isolates pyranometers from their metal mounting platform. Isolation may be useful when the mounting platform does not permit connection of the pyranometer earth ground terminal to the same ground point as the SPD01 or the SCADA system. PID01 also includes spring-loaded fixation for easy pyranometer leveling. Hukx offers an optional pyranometer insulation disc, PID01. Its purpose is to insulate the pyranometer from the—typically metal—mounting platform. This allows users of Hukx industrial pyranometers to use the earthing terminal on the industrial pyranometer to electrically...

Using the PID01 disc is the user’s own decision, and part of the design of the larger earthing and grounding network, leading to a safe workplace, reliable instrument operation and immunity to surges. PID01 is compatible with industrial pyranometer models SR300, SR200, SR100 and also with earlier pyranometer models SR30, SR20 and SR15. Included – insulation disk with spring-loaded pyranometer locking bolt (M6 bolt, 10 mm nut on top, 4 mm hex head) – 2 x M5x12 bolt with 4 mm hex head. Rated mounting plate thickness up to 5 mm, when using included bolts – 2 x M5 washer The insulation disc is spring-loaded....

instrument compatibility industrial pyranometers SR300, SR200, SR100 (with earthing terminal on instrument) earlier pyranometer models SR30, SR20, SR15 (no earthing terminal on instrument) housing material Arnite (White PETP) rated mounting plate thickness 5 mm max, when using included bolts When the center hole at the PID bottom cannot be reached: use a 10 mm spanner.
