Houfek metal

Product catalog summary

Overview: The document provides technical specifications and features of the FOX PBM MAXX series, which are horizontal sanding machines designed for metal surfaces. These machines are versatile and suitable for various industrial applications.

FOX Series Specifications:

Models: FOX 150, 220, 300
Working Table Dimensions: Ranges from 800 x 1500 mm to 800 x 3000 mm
Sanding Belt Width: 150 mm
Sanding Belt Length: Varies from 5400 mm to 8250 mm
Sanding Belt Speed: 8 - 30 m/s
Table Lift: 420 mm (optional 620 mm)
Main Motor Power: 4 kW (optional 5.5 kW)
Exhaust Outlet Diameter: 180 mm
Weight: Ranges from 1100 kg to 1550 kg

PBM Series Specifications:

Models: PBM 15, 20, 30, 40
Working Table Dimensions: Ranges from 1000 x 2000 mm to 1000 x 4500 mm
Sanding Belt Width: 150 mm
Sanding Belt Length: Varies from 6150 mm to 11300 mm
Sanding Belt Speed: 8 - 30 m/s
Table Lift: 500 mm (optional 750 mm)
Main Motor Power: 4 kW (optional 5.5 or 7.5 kW)
Exhaust Outlet Diameter: 200 mm
Weight: Ranges from 1100 kg to 1550 kg

MAXX Series Specifications:

Models: MAXX 2, 3, 4, 5, 6, 8, 9, 10W
Working Width: Ranges from 400 mm to 1550 mm
Features: NC machine control with a color touchscreen, moving or fixed work tables, water cooling with filtration (MAXX 10W)
Working Unit Types: R, D, B, X
Min./Max. Workpiece Height: 0.5 - 160 mm
Feed Belt Motor Speed: 1 - 10 m/min
Sanding Belt Length: 2200 mm to 2620 mm
Sanding Belt Speed: 10 - 35 m/s

Contact Information: HOUFEK a.s., Czech Republic. Phone: +420 569 430 700, Email: [email protected], Website: www.houfek.com

Catalog excerpts

Belt sanders are designed for sanding metal surfaces and workpieces on the working table. They are universal machines with wide range of use. 1 belt horizontal sanding machine for metal 2 belt horizontal sanding machine for metal with standard or vacuum table TECHNICAL DATA FOX 150 220 Working table dimension (L x W) mm Sanding belt width mm Sanding belt length mm Sanding belt speed m/s Main motor power kW Exhaust outlet diameter mm TECHNICAL DATA PBM Working table dimension (L x W) Sanding belt width Sanding belt length Sanding belt speed Table lift Main motor power Exhaust outlet diameter Weight...

Open the catalog to page 2

Deburring machine and metal sander: - with a moving table MAXX 2, MAXX 4 and MAXX 5 - with fixed table MAXX 6, MAXX 8 and MAXX 9 - with fixed table version "WODNIK" MAXX 10W NC machine control, colour Touchscreen disc brushes quick-release handle DRX machine configuration TECHNICAL DATA MAXX Working width NC machine control, colour Touchscreen 15" Moving work table Fixed work table h=900mm Water cooling with filtration Working unit Min./max. workpiece height Feed belt motor frequency inverter - speed Lenght of sanding belt Diameter of the rubbered roller 60Sh Sanding belt speed Disc diameter...

Open the catalog to page 3

CZECH - HEAD OFFICE HOUFEK a.s. 5. května 797 CZ - 582 82 Golčův Jeníkov Czech Republic Prague Golčův Jeníkov Brno Slovakia e-mail: [email protected] www.houfek.com

Open the catalog to page 4
