Welding Reels

Product catalog summary

Introduction
Hose & Reel Products offers a range of hose reels designed for welding applications, including arc welding, gas welding, and cutting operations. These reels are engineered to enhance safety and efficiency by preventing hoses from cluttering the workspace, thereby reducing the risk of accidents. The reels feature a 'LOCK SYSTEM' for controlled hose usage and automatic rewinding options.

Arc Welding Reels

Series SWCR/WCR: These reels support #2 to 4/0 cables up to 400 amps. They offer power or manual rewind options, featuring a 400 amp rated rotary electrical device, quick cable connection, and a non-sparking ratchet assembly. The reels are equipped with a declutching arbor to prevent reverse winding damage and a 4-way roller assembly.

Dual Arc Welding Reels

Series TWCR: Designed for handling both grounding and arc welding leads, these reels feature two spools for separate cable lengths and a 400 amp rotary electrical device. They include Delrin bearings for insulation and ease of operation, along with a gear-driven crank rewind and pinion brake.

Gas Welding Reels

Spring Rewind (N400 Series): These reels handle twin 1/4” to 3/8” welding hoses, featuring a heavy-duty spring motor, non-sparking ratchet assembly, and declutching arbor. They support pressures up to 21 bar and temperatures from -40°C to +93°C.
Manual (MX) or Power Rewind (2400 Series): Available with MX chain drive crank or powered by air or hydraulic motors. These reels handle twin 1/4” to 3/8” hoses, with standard inlets and outlets for oxygen and gas. They support similar pressure and temperature ranges as the spring rewind models.

Specifications and Customization
All models are subject to specification changes and can be customized for different drum lengths and disc sizes. Accessories are available separately, and specific roller positions must be specified when ordering.

Catalog excerpts

Hose > PRODUCTS & Reel > Arc Welding Gas Welding Օ Cutting Operations size="-2">

Open the catalog to page 1

Welding Reels Hose & Reel Products hose reels for welding(Oxygen-acetylene or propane) are particularly recom- mended to obtain a functional working environment in compliance with modern safety regulations. Since the hoses are no longer untidily scattered on the floor, the risk of injuries or any accidental damage to the hoses is considerably reduced. The "LOCK SYSTEM" device allowsyou to use only the hose necessary for the task, while thereturn manual, spring or power rewinds it automatically at the end of the work without waste of time. > Introduction/Contents Reel Type I.D. Hose Sizes Page...

Open the catalog to page 2

Welding Reels to handle #2 through 4/0 cable to 400 amps. Standard Configuration ShownSeries SWCR Standard Configuration ShownSeries WCR 1. Specifications subject to change. 2. Upon request, reels can be supplied with drum lengths other than shown and with disc sizes in other diameters.3. When ordering power rewind Series WCR, prefix model number with: A = Air Rewind EP = Electric Rewind ( 12v -24v DC, explosion proof ) HD = Hydraulic Rewind 4. Accessory seperated. A Series SWCR

Open the catalog to page 3

Welding Reels to handle #1 through 4/0 cable to 400 amps. Standard Configuration Shown 1. Specifications subject to change. 2. Accessory seperated.

Open the catalog to page 4

Welding Reels

Welding Reels
