Introduction
Hose & Reel Products BV is a prominent European distributor specializing in high-quality hose and cable reels for diverse applications such as washdown, chemical transfer, potable water, food processing, pharmaceuticals, cosmetics, fueling, fire protection, dairy operations, and bottling plants. The catalog outlines specifications for popular hose reels, with customization options available upon request.

Types of Hose Reels

Spring Rewind Reels: These reels, available in models like N500, N600, and N700, accommodate various hose sizes and feature a compact frame, non-sparking ratchet assembly, and declutching arbor to prevent reverse winding damage. They support pressures up to 689 bar and temperatures from -40°C to +121°C.
Manual Rewind Reels: Designed for pressure washing and spray operations, these lightweight reels include a direct crank rewind and adjustable cam lock brake, supporting pressures up to 207 bar and temperatures from -7°C to +200°C.
Power Rewind Reels: Suitable for applications requiring long hose lengths, these reels can be powered by electric, hydraulic, or other means.
Storage Reels: Available in various sizes and configurations, these reels are used for storing hoses.

Specifications and Features

Reels are designed for different hose sizes, with models catering to hose diameters from 1/4" to 3".
Standard features include non-sparking ratchet assemblies, declutching arbors, and 4-way roller assemblies.
Inlet and outlet threads are typically BSPT, with customization options available.
Constructed with durable materials, these reels are suitable for heavy-duty applications.

Notes and Recommendations

Specifications may change, and customers should consult Hose & Reel Products for specific requirements, especially for vertical lift applications.
Detailed parts breakdowns are available upon request.
Accessories are sold separately.

Overview
This document provides technical specifications and details for various models of industrial hose reels designed for applications such as air compressors, hydraulics, fuel dispensing, and more. Reels are available in manual or power rewind options, with various pressure and temperature capabilities.

Specifications

Reels feature direct crank rewind, cam lock drag brake, and spring-actuated pin lock. They have standard inlet and outlet threads, with optional rollers available. Pressure capacity ranges up to 690 bar, and temperature tolerance spans from -51°C to +204°C, depending on the model.

Model Variations
The document lists multiple models, each with specific hose capacities, dimensions, and weights. Models are categorized based on the hose internal diameter (I.D.) they can handle, ranging from 1/4” to 1-3/4”.

Rewind Options
Reels can be ordered with different rewind mechanisms: air, electric, or hydraulic. The document specifies model prefixes for each rewind type.

Applications
The reels are suitable for various industrial applications, including air compressors, washdown, hydraulics, fuel dispensing, fire protection, and chemical transfer. Some models are specifically designed for dual hose handling.

Notes

Specifications are subject to change, and customizations such as different drum lengths and disc sizes are available upon request.
Detailed parts breakdowns can be requested using specific ISO numbers.

Key Features

Reels are available with manual or power rewind options, including air, electric, or hydraulic motors.
Standard inlets and outlets are equipped with BSPT threads, with optional materials like bronze or stainless steel available.
Reels can be customized with different drum lengths and disc sizes upon request.
Accessories such as rollers and divider discs are available for purchase.

Notes

Specifications are subject to change.
Detailed parts breakdown drawings can be requested for specific models.
Explosion-proof switches are available for certain models.

Catalog excerpts

Hose > PRODUCTS & Reel > Washdown Chemical Transfer Օ Potable Water Food ProcessingFarmaceuticals & Cosmetics Օ Fueling Fire Protection Օ Dairy OperationsBottling Plants size="-2">

Open the catalog to page 1

Industrial Reel Hose & Reel Products is the biggest european distri-butor of high quality hose and cable reels for most every conceivable application. This catalog describes and gives specifications on our most popular hose reels. If you dont see what youҒre looking for, give us a call and we will help you to meet your needs. Spring Rewind Reels Manual Rewind Reels Compact Manual Rewind Reels Power Rewind Reels > Introduction/Contents

Open the catalog to page 2

Industrial Reel to handle single 1/2 through 1ԓ I.D. hose 1. Specifications subject to change. 2. Upon request, reels can be supplied with drum lengths other than shown and with disc sizes in other diameters. > B XAFYDHGE 3. Dimensions shown for reels up to and including 30-31 disc size reflect pressed frames. All others are rollformed channel frames.4. For a detailed parts breakdown drawing, request ISO 84. 5. Accessory seperated. 6. When ordering power rewind models, prefix model number with: > C 10.5 267 A = Air Rewind EP = Electric Rewind ( 12v -115v DC) HD = Hydraulic Rewind Explosion proof...

Open the catalog to page 20

Industrial Reel to handle single 1-1/2Ք or 2 I.D. hose 1. Specifications subject to change.2. Upon request, reels can be supplied with drum lengths other thanshown > B XAFYDHGE and with disc sizes in other diameters.3. For a detailed parts breakdown drawing, request ISO 35.4. Accessory seperated.5. When ordering power rewind models, prefix model number with: A = Air Rewind EP = Electric Rewind ( > C 15.5 12v -115v DC) > 393 HD = Hydraulic Rewind Explosion proof switch, w/EXPB-2A > For Power Rewind see note 5 > (in) 2-1/162-9/16Ԕ (kg) NET ON REQUEST ON REQUEST ON REQUEST ON REQUEST >

Open the catalog to page 23

Industrial Reel to handle 2Ք through 3 I.D. hose 1. Specifications subject to change. 2. Upon request, reels can be supplied with drum lengths other than shown > E H B YDXAF and with disc sizes in other diameters.3. For a detailed parts breakdown drawing, request ISO 57.4. Accessory seperated.5. When ordering power rewind models, prefix model number with: A = Air Rewind EP = Electric Rewind ( > C 20 12v -115v DC) > 508 HD = Hydraulic Rewind Explosion proof switch, w/EXPB-2A > For Power Rewind see note 5 > (in) 2--9/163-3/16Ԕ3-3/4 (kg) NET ON REQUEST ON REQUEST ON REQUEST ON REQUEST >

Open the catalog to page 24

Industrial Reel to handle 3/8Д through 5/8 I.D. hose

Open the catalog to page 25

Industrial Reel to handle 1/2Д through 1 I.D. hose

Open the catalog to page 26
