XL Prime Series
2Pages

Class I, Division 2 Groups A, B, C, D Type 4X The World’s Most Advanced All-In-One Controller Just Outdid Itself New users will be impressed by the power and speed... Current users will love the seamless transition from the XL Series! For years, the Horner XL Series has enjoyed a reputation as the most highly functional All-in-one Controller available anywhere. These products are currently trusted with thousands of applications world-wide. The NEW XL Prime Series builds upon that proven reputation – offering new and existing users alike performance upgrades and a highly secure, modern memory architecture. This is accomplished with a new Horner designed System on Module (SOM) - containing a faster CPU, onboard mass storage and 100% non-volatile memory. The only battery is a small coin cell – simply tasked with maintaining the clock. If you are a new automation designer looking for an innovative, reliable control solution – the XL Prime Series offers a fully integrated product in hardware and software. If you are an existing XL Series user – your current application program will port straight through in less than 30 seconds. In either case you can’t go wrong! FEATURES: ALL-IN-ONE CONTROL - performs all machine functions in a unified hardware design; Logic Control, Operator Interface, I/O and Networking. MODERN MEMORY ARCHITECTURE - based on a custom designed SOM (System on Module) utilizing a powerful ARM microprocessor and 100% nonvolatile memory for reliability. HIGH-PERFORMANCE LOGIC ENGINE - fast scan times solving user logic using Variable-based Advanced Ladder logic or the IEC 6-1131 language set. ONLINE PROGRAMMING - make logic changes without stopping the *Models X5 & XL15 coming soon... HIGH-RESOLUTION COLOR TOUCHSCREEN - for detailed graphics and nearly instantaneous screen updates. ADVANCED HIGH-SPEED COUNTER - four built-in counters supporting frequencies over 500 kHz. INDUSTRIAL ETHERNET AND REMOTE CONTROL - Ethernet IP, Modbus TCP and BACnet IP; FTP file transfer, Email. WebMI* for web-based Remote Monitoring; Push data to the cloud with MQTT* Sparkplug. *WebMI/MQTT require one-time license. PLUG-AND-PLAY DATALOGGING - record machine and process variables to microSD or USB Flash Drive. 59 South State Ave., Indianapolis, IN 46201 | (p) 317.916.4274 (tf) 877.665.5666 (f) 317.639.4279 | www.hornerautomation.com Please visit our website for a complete listing and to learn more about certified Horner Automation products.

Class I, Division 2 Groups A, B, C, D Type 4X XL PRIME SERIES PART NUMBERS I/O OPTION *This model coming soon; X5 Prime is available in noted model only LOGIC CONTROLLER X5 Option (only) Option 0 Logic Scan Rate Logic Program Size Program Variables I/O Variables Logic Languages 1,024 words & 4,096 bits Horner Advanced Ladder IEC 6-1131 12 DC In, 12 DC Out, 2 – 14/16-bit Analog In (mA/V/Tc/mV/RTD), 2 – 12-bit Analog Out (mA/V) 12 DC In, 12 DC Out, 6 – 14/17-bit Analog In (mA/V/Tc/mV/RTD), 4 – 12-bit Analog Out (mA/V) All Models Support SmartRail, SmartBlock, SmartStix, SmartMod and OCSI/O...
