HPT604-BH

Product catalog summary

Overview: The HPT604 (Type BH) is a highly precise and stable submersible pressure transducer and transmitter designed for various applications including level measurement in bio-fuels, gasoline, diesel fuel tanks, ballast tanks, groundwater, irrigation equipment, and pumping stations. It features both analog and digital outputs.

Applications: The device is suitable for level measurement in bio-fuels, gasoline and diesel fuel tanks, ballast tanks, groundwater, and irrigation equipment. It is also used for controlling pumping stations.

Features: Key features include a TE pressure cell with 0.25% full-scale accuracy, EMI/RFI protection, customizable level ranges from 50 cm to 200 m, optional PT100 temperature measurement, and an IP68 waterproof design. It is approved by CE, RoHS, ATEX, and IECEx standards.

Technical Specifications: The transducer offers a pressure range from 0 to 5 bar, with overload and burst pressures at 150% and 500% of full scale, respectively. It provides accuracy options of ≤ ±0.5% F.S, with long-term stability of ≤ ±0.2% F.S per year. The working temperature ranges from -40°C to +85°C, and it is compatible with 304 stainless steel.

Electrical Specifications: The device supports various signal outputs including 4-20 mA, 0-5 V, 0-10 V, and RS485 Modbus RTU. It operates on power supplies ranging from 3.6 to 30 V DC and features reverse polarity protection for power lines.

Ordering Information: Customers can select from a range of options including pressure and level units, pressure types, signal outputs, power supplies, measuring mediums, and cable lengths. Accessories such as liquid level display control devices, locking flanges, and surge protectors are available separately.

Certifications: The transducer is certified under ATEX, IECEx, RoHS, and CE standards, ensuring compliance with safety and environmental regulations.

Catalog excerpts

1. Pressure Measurement 2. Level Measurement 3. Temperature Measurement 4. Flow Measurement 5. Display & Control Instruments 6.Wireless Monitoring System 7.Velocity Measurement

Open the catalog to page 1

HPT 604 (Type BH)Highly Precise and Stable Type Submersible Analog & Digital Pressure Fuel Level Transducer & Transmitter| Applications • Level Measurement in Bio-Fuels • Monitoring of Gasoline & Diesel FuelTanks • Level Measurement in BallastTanks • Level Measurement in Ground WaterLevel • Monitoring of Irrigation Equipment • Control of Pumping Stations | Features • Imported TE pressure cell, 0.25%F.S • Survives Harsh Environments • EMI/RFI Protection • Custom level ranges from 50cmto 200m • Optional PT100 temperature measurement • IP68 full sealed plastic waterproofdesign • CE, RoHS, ATEX,...

Open the catalog to page 2

•DATASHEET- LEVEL MEASUREMENT Ambient Temperature: 25°C (unless specified)

Open the catalog to page 3

| Dimensions and Drawing Unit, mm

Open the catalog to page 4

•DATASHEET- LEVEL MEASUREMENT 1. Range Selection Table: Pressure Type E5 S11 D3 N 1 003 G=Gauge/Relative pressure type (universal) A=Absolute pressure (customized) Signal Output CW=Water D1=0.84g/cm3 density diesel D2=0.83g/cm3 density diesel Measuring D3=0.85g/cm3 density diesel D4=0.86g/cm3 density diesel Medium G2=0.725g/cm3 density gasoline G5=0.737g/cm3 density gasoline X=Others Liquid and Density By customized Others Function (Optional) T=With Temperature Sensor/Output (only RS485) FC=FEP Cable Cable Length 001= Cable 1m 002= Cable 2m 003= Cable 3m X= By customized (Model: HPT604-BH, fuel...

Open the catalog to page 5

•DATASHEET- level MEASUREMENT Order number Liquid level display control device 0008 With all kinds of liquid level sensor, measurement according to liquid level, and according to the setting of the container structure and size and the density of liquid, calculation, display liquid volume or quality. Locking flange For locking cables, made of aluminum alloy IP68 rated deep water level cable extender Mainly used to extend the cable of deep water level transmitter. Users can rewire it locally. It can work continuously for more than 10 years 500 meters underwater, and the safe tensile strength of...
