Insertion Electromagnetic flow meter Description Holykell Insertion electromagnetic flow meter is composed of insertion electromagnetic sensor and electromagnetic flow converter, used to measure the conductive liquid that electrical conductivity is greater than 5 us/cm , it is used to measure the water, sewage, acid, alkali and other medium. Suitable for measuring the large pipe of diameter DN300~DN3000mm,. Installation can be divided into a online installation type of the cut-off valve and water control installation type without stop valves. are applied to measuring volume flow of conducting...

Main specification Flow sensor Accuracy Pipe size Operating pressure Medium Temp Flow range Power Consumption Protection grade Connection method Flow transmitter Signal output Communication protocol Protection grade Indicator style LCD display with back light Flow unit Signal terminal type Entry cable Power supply A comparison table of several common pipe inner diameters, average flow rates (m/s), and volume flow rates (m3/h). DN（mm）

Electronic Connections Installation 1. The installation position should be full of liquid. 2. The internal diameter or perimeter of pipeline should be measured easily, and ovality should be small. 3. The length of straight pipe on upstream should be more than 10D, and downstream should be more than 5D, D is the diameter of pipeline. 4. Vertical installation, the sensor should be vertical with axis, the included angle with cross section should be less than 5°. 5.There are two ways to insert the sensor: 1/4 of the pipe inner diameter or 1/2 of the pipe inner diameter. 6.Weld the installed base...

Selection Type F = Remote type (standard with 10m cable) Y = Compact type S = 316L T = Titanium(Ti) D = Tantalum(Ta) C = Hastelloy C(HC) P =Platinum iridium alloy 1 = 110~240V AC Power Supply 2 = 24V DC 3 = Lithium battery(without output signal) Output signal H = HART Protocol R = MODBUS RS485 G = GPRS J = Without a ball valve B = With a ball valve
