HIRSCHMANN
Product overview

Product overview

Product catalog summary

Overview
The document emphasizes the critical role of speed and reliability in industrial manufacturing, highlighting Hirschmann Electronics' contributions to automation and network solutions. It underscores the necessity for high operational reliability and availability across industries such as automotive, transportation, and food processing.

Product Range
Hirschmann offers a diverse array of products, including connectors, field bus systems, and industrial Ethernet components, designed to maintain uninterrupted operations under challenging conditions like contamination, moisture, or vibration.

Key Product Lines

E-series: Circular connectors for sensors and actuators, featuring compact design, quick installation, and high protection class (up to IP 68/69 K).
FIXCON® series: Circular connectors with fast-lock technology, eliminating the need for screw connections.
GDM-series: Rectangular connectors for hydraulic, pneumatic, and electromagnetic actuators, built to withstand heavy stresses.
G-series: Space-saving rectangular connectors for narrow spaces, suitable for actuators and sensors.
CA-/CM-series: Robust circular connectors for measurement, control, and regulation technology, offering high vibration resistance.
NR-series: Circular connectors made of solid metal, suitable for extreme conditions.

Applications
The document details various applications for each product series, highlighting their suitability for automation technology, hydraulic and pneumatic systems, and environments with high vibration stresses.

Quality Assurance
Hirschmann ensures product reliability and performance through extensive testing before delivery.

ST-Series Bus Connectors
Specifications: Designed for power supplies and data transmission, offering dust and splash-proof protection, VDE and UL permits, available in 3- to 6-pole variants, supporting voltages up to 400 V and currents up to 16 A, with a protection class up to IP 54.
Applications: Suitable for industrial installations and building automation.

MAS-/MAK-series and SunCon-series
Specifications: Circular connectors for hi-fi and audio-visual media, offering secure connections. SunCon connectors are designed for solar systems, offering quick assembly and high protection.
Applications: Used in entertainment electronics and photovoltaics.

Test and Measurement Series
Specifications: Precision test equipment with a broad range of products for gripping, sensing, and connecting, with safety system contact protected up to 1,000 V.
Applications: Tailor-made for various measurement applications from millivolt to kilovolt.

OpenConnector and Connectors Unlimited
Specifications: Offers customizable solutions with options for cable length, design, and printing, providing maximum flexibility beyond catalog products.
Applications: Encompasses all Hirschmann connector ranges, offering reliable connections.

Quality Assurance
Emphasizes the importance of high-quality connectors to prevent machinery breakdowns and ensure operational reliability. Hirschmann's commitment to quality is presented as a crucial factor in maintaining competitive advantage in the global market.

Contact Information
Provides contact details for Hirschmann offices in various countries, ensuring accessibility for customer inquiries and support.

Catalog excerpts

Circular connectors for extremely rough environments Circular connectors,when your requirement calls for metal Requirements and Solutions Requirements and Solutions The robust circular connectors of the CA-/CM-series meet the most stringent requirements of general equipments in the field ofmeasurement, control and regulation technology. Space-saving circular connectors of the NR-series are made of solid metal and therefore ensure long-term solutions in the field of network and control wireconnections. Product features preferably with plastic or metal housing (for extremely robust solutions)Օhigh...

Open the catalog to page 6

Circular connectors in global standard Solar connector with rapid assembly Requirements and Solutions Requirements and Solutions Circular connectors of MAS-/MAK-series set a global standard The SunCon connector system allows you to assemble connectors for hi-fi and audio-visual media,offer secure connections in the field quickly and easily without special tools when installing solar of computers and interfaces. systems on roofs or solar parks. It has a high protection type and an extremely long shelf life. Product features compact design for use in small spaces Օquick to assemblesecure, easy...

Open the catalog to page 8

General catalog Product overview MAS-/MAK-series Industrial ETHERNET General catalog General catalog Industrial Connectors Industrial ETHERNET Product overview General catalog Test & Measurement FiberINTERFACES General catalog Product overview Test & Measurement FiberINTERFACES/ Field bus components >

Open the catalog to page 11
