High Pressure Valves & Fittings

HIGH SERVICE HIGH QUALITY HIGH PERFORMANCE High Pressure equipment Hydrogen Fuel Station Needle Valve 05 High Pressure Needle Valve 06 High Pressure Check Valve & Line Filter 12 High Pressure Fitting 14 High Pressure Fitting Accessory 16 Tube Cap / Oil Based Thread Lubricant 17 Safety Head & Rupture Disc 18 High Pressure Ball Valve 19 Relief Valve - Factory Set 22 Relief Valve - Field Adjustable 23 Relief Valve - Proportional Type 25 Relief Valve - Proportional GAS 27 Wellhead Gauge Valve 32 Double Block and Bleed Valve 34 High Temperature Valve 35 High Pressure Tube 37 High Pressure Nipple 38...

Passion for a high-pressure future, constant challenge and innovation HIFLUX Co.,Ltd.hasbeenrecognizedforitstechnologicalprowessbysuccessfullyproducingvariousofhigh-pressure pipingmaterialsthataredifficulttomanufacturedomesticallythroughcontinuousR&Dandfacilityinvestmenttoopen upnewmarketsintheultra-highpressurepipingmaterialssector. Based on differentiated technological prowess and price competitiveness compared to overseas manufacturers in EuropeandtheUnitedStates,itisgrowingintoaglobalbrandbyconcludingOEMsupplycontractswithdomesticOEM suppliersandoverseasglobalwaterjetmanufacturers. In addition,...

HIFLUX HISTORY 2024.05. Selected as a 'Hydrogen Specialist Company' by Government 2023.10. Acquired 'KS certification for manual valve for hydrogen refueling station' by KGS 2023.05. KS Q ISO 45001 certification 2023.05. Selected as a 2023 HIFLUX Small Giant Company 2021.08. Patent (Double-sealed check valve) acquired 2021.07. Received a commendation from KGS 2021.03. Patent (High-pressure valve) acquired 2020.07. 'Material/Component/Equipment Specialist Company Confirmation' acquired 2020.07. Patent (High-temperature/high-pressure valve) acquired 2020.06. R&D (Valve and fittings for H70 hydrogen...

simply indicate catalog number and specify option or special requirement © Pressure® Type of Components © Material © Tube Size HRS-NV : Hydrogen Refueling System Needle Valve NV : Needle Valve CV : Check Valve BV : Ball Valve ABV : Actuater Ball Valve AOV : Air Operated Valve RV : Relief Valve KGC-RV : Gsa Relief Valve SH : Safety Head CON : Control Valve HV : High Temperature Valve GV : Wellhead Gauge Valve BLV : Bleed Valve P : PT DBBV : Double Block and Bleed Valve FT : Fitting FA : Fitting Accessory MF : Manifold Block FATC : Tube Cap T:Tube N : Nipple A : Adapter BPR : Back Pressure Regulator...

High pressure tubing for optimal tubing effect • The tube is sold in basic 6M units. • Excellent corrosion resistance required at high pressure due to the use of cold-formed stainless steel 316 material • Tubing used in the chemical, oil refining, research, oil, and gas industries for various pressures (up to 150,000 psi) • If you want a hydraulic test, we can perform it on your behalf according to the rules (Gas Safety Act) set under the operating pressure. All dimensions are for reference only and may differ from actual size.

High pressure nipples for easy and quick configuration of equipment and piping ■ Cone and Thread Nipple for easy and quick equipment configuration ■ Excellent corrosion resistance required at high pressure due to use of cold-formed stainless steel 316 ■ Can be manufactured in two types: one-way and two-way All dimensions are for reference only and may differ from actual size. One Side Type Both Side Type

Port Type Low PressurePortType Sleeve TypeConnections-10,000psi/15,000psi Sleeve Type is a method of attaching a sleeve inside a gland and can be used on 1/8", 1/4", 3/8", and 1/2" pipes. The tubes used for connecting products can be ordered from HIFLUX Mall and are made of stainless steel to ensure optimal performance in high-pressure environments. Tubing Gland Sleeve High PressureValves&Fittings

Port Type Medium PressurePortType Medium PressureConnections-20,000psi ProductsareconnectedusingCollar and Nipplewithin the Gland, and the Nipple required for connecting products can be ordered in the desired length by the user, and can also be processed directly using our toolingset. Nipple Gland

Port Type High PressurePortType High Pressure Connections - 30,000 psi / 60,000 psi The Nipple required for connection between the products by using collar and Nipple in the Gland can be ordered by user's desired length. you can also process directly using our Tooling Set tool. this cone and threaded connection is the standard for easy and fast high-pressure equipment configuration with optimum sealing and reliable performance for both liquid andgasathighpressureandtemperature. Nipple Gland

Port Type Ultra HighPressurePortType Ultra High Pressure Connections - 100,000 psi / 150,000 psi The productisconnectedusingacollarandnipplewithinthegland,andthecorrespondingpipesizesareasfollows. ThisConeandThreadmethodconnectionistheoptimalsealingmethod,anditprovidesreliableperformanceforboth liquids and gases at high pressures and temperatures, and is the standard for easy and quick high-pressure equipmentconfiguration. Gland Collar Gland Collar

Recommended Torque All dimensions are for reference only and may differ from actual size. Q HIFLUX Needle Valve Assembly Torque Chart Valve Pressure Series Torque values apply to glass-impregnated Teflon packaging and may vary by ±10% 62 1 High Pressure Valves & Fittings

HIFLUX Co.,LTD St. EdburgsHall,PrioryRd Bicester, OX266BL United Kingdom E-mail &Online E-mail. [email protected] Web. www.hiflux.uk.com
