Overview
The Hiab Multilift XR 2S is a versatile hooklift designed for light commercial trucks, particularly beneficial for gardeners and similar professions. It enhances the performance and flexibility of 3.5-tonne trucks, allowing for efficient loading, unloading, and tipping of the body.

Performance and Versatility
Despite its compact size, the XR 2S offers significant performance capabilities. It allows for the transportation of machinery and materials without idle time, boosting truck productivity. The design utilizes advanced 3D-CAD methods and modern production technology, resulting in a strong structure with minimal welding. This design provides a low weight-to-strength ratio, enabling larger payloads and increased vehicle versatility.

Safety Features
Safety is a priority in the XR-series, featuring load-holding valves on the cylinders and a tipping lock mechanism. The series complies with the EU's Directive on the Safety of Machinery.

Technical Specifications

• Type: XR 2S
• Capacity: 2,000 kg
• GVW of Vehicle: 3.5 tonnes
• Container Length (internal): 3.0 to 4.0 meters
• G-Length: 2700 to 3200 mm
• Equipment Weight: 390 to 430 kg
• Tipping Angle: 47 to 49 degrees
• Hook Height: 900 / 930 mm
• Body Level: 135 mm
• Max. Operating Pressure: 18 MPa
• Recommended Oil Flow: 15-20 l/min

Company Information
Cargotec Finland Oy, located in Raisio, Finland, is part of Cargotec, a global leader in cargo and load handling solutions. Cargotec's brands, including Hiab, Kalmar, and MacGregor, are recognized worldwide for their efficiency and reliability in cargo flow management.
