Heyco Custom Turn-2-Lock Cord and Plug Sets - NEMA 15, 20 & 30 Amp Configurations

Product catalog summary

Overview: Heyco's Custom Turn-2-Lock Cord and Plug Sets are designed for highbay and lowbay lighting, display cases, commercial cooking, laundry, construction, and other specialty equipment. These sets ensure secure connections, preventing accidental disconnections.

Specifications: The cord and plug sets are available in lengths from 12 inches to over 15 feet, with both male and female NEMA configurations. They support voltages of 125, 250, 277, 347, and 480 volts, and amperages of 15, 20, and 30 amps. Standard colors are black and white, with custom colors available upon request.

Materials: The products use PVC overmold, nylon 6/6 premold, and 70/30 brass for the blades. Alloy 260 (70/30 Brass) is specifically used for durability.

Customization Options: Heyco offers custom lengths, terminations, strain reliefs, and other configurations. Strain reliefs can be metallic or non-metallic, and cordgrips or terminals can be pre-attached to save time and reduce costs.

Accessories: Common accessories include ring terminals and strain relief devices, with part numbers provided for specific configurations.

Compliance: The products are recognized for use in the U.S. and Canada under File E217650 and are ISO9001:2008 certified.

Product Range: The document lists various part numbers for different configurations, detailing wire gauge, color, type, and length. It includes configurations for different NEMA plugs and wire types such as SJTW, STOW, SEOOW, and SEOW.

Contact Information: For custom configurations or further inquiries, customers are encouraged to contact Heyco through their provided phone numbers and website.

Catalog excerpts

Heyco Custom Turn-2-Lock Cord and Plug Sets - NEMA 15, 20 & 30 Amp Configurations-2

Heyco® Custom Turn-2-Lock Cord and Plug Sets Male and Female Configurations New Heyco® Custom Turn-2-Lock Cord and Plug Sets are specifically designed for use in highbay and lowbay lighting, display cases, commercial cooking, laundry, construction, and other specialty equipment where the possibility of the male and female ends of the plug becoming easily disconnected is not an option. • We offer 12˝ to 15+ feet Turn-2-Lock Whips in both Male and Female NEMA configurations. • Popular 125, 250, 277, 347, and 480 Volt; with 15, 20, and 30 Amp NEMA configurations available. • Standard colors are...

Open the catalog to page 2

Heyco Custom Turn-2-Lock Cord and Plug Sets - NEMA 15, 20 & 30 Amp Configurations-3

Custom Female Configurations <ftlus Recognized for Use in the U.S. and Canada Under File E217650 Commonly Applied Turn-2-Lock Accessories PLUG END STRAIN RELIEF OR LIQUID TIGHT FITTING -

Open the catalog to page 3

Heyco Custom Turn-2-Lock Cord and Plug Sets - NEMA 15, 20 & 30 Amp Configurations-4

Custom Male Configurations c®»s Listed for Use in the U.S. and Canada Under File E217650

Open the catalog to page 4

Heyco Custom Turn-2-Lock Cord and Plug Sets - NEMA 15, 20 & 30 Amp Configurations-5

Custom Male Configurations continued c®»s Listed for Use in the U.S. and Canada Under File E217650 Don't see the configuration you need? Consult Heyco for your particular NEMA Plug; wire gauge, type, length, and color; and Strain Relief and Termination requirements. OurAxcell® rapid development team is ready to meet your design requirements.

Open the catalog to page 5

Heyco Custom Turn-2-Lock Cord and Plug Sets - NEMA 15, 20 & 30 Amp Configurations-6

Custom Male Configurations continued c®»s Listed for Use in the U.S. and Canada Under File E217650

Open the catalog to page 6

Heyco Custom Turn-2-Lock Cord and Plug Sets - NEMA 15, 20 & 30 Amp Configurations-7

Custom Male Configurations concluded c®»s Listed for Use in the U.S. and Canada Under File E217650 Still don't see the configuration you need? Consult Heyco for your particular NEMA Plug; wire gauge, type, length, and color; and Strain Relief and Termination requirements. OurAxcell® rapid development team is ready to meet your design requirements.

Open the catalog to page 7

Heyco Custom Turn-2-Lock Cord and Plug Sets - NEMA 15, 20 & 30 Amp Configurations-8

The Strain Reliever™ “Pill Bottle” INDICATIONS: For permanent relief of strain associated with not having the solution. DIRECTIONS: Remove top and shake out a potential solution. Take one dose each time “no solution” symptoms appear. Repeat as needed. This prescription may be refilled at any time because new solutions are constantly being generated. WARNING: If strain persists or gets worse, consult your Heyco representative immediately because this could be a sign of a serious problem in need of a Heyco solution! Request one from your Heyco Distributor, Sales Representative, Business Development...
