Product catalog summary

Overview
Hexcel offers a range of Redux® and HexBond™ adhesives, including film adhesives, foaming films, primers, and liquid shims, tailored for aerospace and industrial applications. These products are designed for bonding composites and metals, ensuring high performance and durability.

Film Adhesives
Redux® and HexBond™ film adhesives are available in epoxy and bismaleimide forms, requiring heat and pressure for curing. They are suitable for metal-to-metal and composite bonding, as well as honeycomb sandwich structures, with temperature resistance from -55ºC to 230ºC.

Foaming Adhesive Films
These films expand when cured at high temperatures, ideal for gap filling and honeycomb core bonding, and are used with Redux® film adhesives.

Primers
Redux® primers enhance adhesive performance by protecting pretreated metal surfaces and ensuring bond durability, free of chromium compounds.

Shimming and Paste Adhesives
Shimming adhesives are two-part epoxies that cure at room or elevated temperatures. HexBond™ paste adhesives are available in one and two-component forms for bonding, potting, and filling applications.

Adhesive Selection Criteria
Selection is based on factors like maximum service temperature, cure temperature, bondline thickness control, weight, and material compatibility. Film adhesives are categorized by curing temperatures, typically 120ºC or 180ºC.

Product Performance
The guide details specifications for Redux® and HexBond™ products, including service temperatures, cure times, and mechanical properties like lap shear strength and peel performance, aiding in selecting the right adhesive for specific applications.

Conclusion
Hexcel's Redux® and HexBond™ adhesives provide versatile solutions for bonding in demanding environments, focusing on performance, durability, and substrate compatibility.

Specifications
1. HexBond™ EA 9351MB: Low-density adhesive for bonding fasteners and inserts, with a service temperature range from -55°C to 180°C.
2. HexBond™ ST1009C: Conductive paste adhesive suitable for applications requiring electrical conductance, with a service temperature range from -55°C to 150°C.
3. HexBond™ EA 9685-1: Used in self-stiffened composite panels, with a cure temperature of 180°C.

Applications
1. Aerospace: Used in primary structures like landing gear doors and radomes.
2. Interiors: Suitable for galleys, floor panels, and partitions.
3. Industrial: Applicable in automotive, buildings, marine, rail, sports goods, tooling, and wind energy sectors.

Product Family
Hexcel offers a wide range of composite materials including HiTape® Advanced Reinforcements, Modipur® Polyurethane, HexWeb® Engineered Core, HexTow® Carbon Fiber, HexFlow® Resins, HexMC® Molding Composite, HexPly® Prepregs, HexTool® Tooling Material, Redux® & HexBond™ Adhesives, Polyspeed® Laminates, HexWeb® Honeycomb Core, and HiMax™ Multiaxial Reinforcements.

Disclaimer
Hexcel provides technical data considered accurate as of the document's issue date but reserves the right to update or modify this information. Performance values are representative and should not replace testing for specific purposes. Hexcel disclaims any liability related to the use of this information.

Catalog excerpts

Redux® & HexBond™ Adhesives Selector Guide Providing practical and economical solutions for joining composites and metal.

Open the catalog to page 1

Hexcel’s adhesives have been used in the composites industry for over 70 years They have achieved worldwide acclaim for aerospace and industrial bonding They are an efficient method of joining component pieces quickly and Redux® and HexBond™ Film Adhesives, Foaming Films, Primers and Liquid Shims Hexcel formulates and manufactures a comprehensive range of structural film adhesives, foaming adhesive films, paste adhesives, liquid shims and primers for aerospace and industrial markets. Redux® and HexBond™ Film Adhesives Epoxy and bismaleimide (BMI) adhesives are supplied in film form on a roll...

Open the catalog to page 2

The comprehensive range of Redux® and HexBond™ adhesives are suitable for many different applications. The first stage of design for bonding is the selection of the most suitable adhesive. This selector guide gives a summary of the main properties of the standard adhesive range. Generic Type Hexcel film adhesives are supplied in two generic types: 1. Epoxy - giving higher strengths, toughness and temperature resistance up to 200°C (390°F). 2. Bismaleimide - giving good performance at even higher temperature resistance up to 230°C (450°F). Maximum Service Temperature The temperature at which adequate...

Open the catalog to page 3

Ideal for industrial bonding applications such as: building panels, rail carriage doors, flooring partitions. Flexible cure cycle from 100 - 150°C to (212 - 300°F).

Open the catalog to page 4

Widely qualified for space applications

Open the catalog to page 6

Typical Aerospace Applications Hexcel is the preferred supplier of composite materials to the civil aerospace industry with materials present in virtually every commercial aircraft currently built in the western world. Primary Structures landing gear doors ¥¥ Trailing edge upper and lower panels ¥¥ Main and centre landing gear doors ¥¥ Pylon fairings and nacelles ¥¥ Belly fairing panels ¥¥ Spoilers/flaps/ailerons ¥¥ Horizontal (HTP) and vertical (VTP) stabilizer ¥¥ Radome panels stowage bins ¥¥ Wall partitions ¥¥ Lavatory ¥¥ Wardrobes ¥¥ Ceiling panels ¥¥ Sidewalls ¥¥ Overhead Typical Industrial...

Open the catalog to page 7

Hexcel Product Family HexTow® Carbon Fiber HexFlow® Resins HexMC® Molding Composite HexForce® Reinforcements Polyspeed® Laminates HexWeb® Honeycomb Core HiTape® Advanced Reinforcements Modipur® Polyurethane HexWeb® Engineered Core HexPly® Prepregs Redux® & HexBond™ Adhesives HexTool® Tooling Material HiMax™ Multiaxial Reinforcements For more information Hexcel is a leading worldwide supplier of composite materials to aerospace and industrial markets. Our comprehensive range includes: ¥¥ HexTow® carbon fibers ® ¥¥ HexForce reinforcements ¥¥ HiMax™ multiaxial reinforcements ¥¥ HexPly® prepregs...

Open the catalog to page 8
