Modbus/TCP
Product catalog summary
Overview: The TB20-C is a Modbus/TCP bus coupler designed for industrial automation, allowing data access from peripheral modules using the Modbus/TCP protocol. It supports up to 64 modules connected in series and features an integrated two-port switch for star and line topology configurations.
Key Features:
- Hot-swapping capability for module replacement during operation.
- 24 V DC power supply with an integrated unit for peripheral modules (2.5 A).
- USB device port for diagnostics, parameter configuration, setup, and firmware updates using the "TB20 ToolBox".
- Simultaneous access to up to 10 stations (TCP connections).
- Large I/O image table size of 2048 bytes for input and output data.
- Control and status registers for configuring and monitoring the coupler's behavior.
- Supports Modbus function codes 1, 2, 3, 4, 5, 6, 15, 16, 22, 23.
Technical Specifications:
- Order number: 600-170-1AA11
- Dimensions: 110 x 35 x 73 mm; Weight: Approx. 115 g
- Transmission rate: 10/100 Mbps with automatic detection
- Connection: 2 x RJ45 for Modbus interface, 1 x Mini-USB for USB interface
- Electrical isolation: 1.5 kV
- Voltage supply: 24 VDC, range 18–28 VDC
- Current draw without modules: 75 mA; Power dissipation: Max. 8 W
- Ambient temperature: 0 °C to +60 °C; Storage temperature: -20 °C to +80 °C
- Protection rating: IP 20
- Certifications: CE, UL; Compliance with RoHS and REACH
Environmental and Compliance:
- Noise immunity: DIN EN 61000-6-2 “EMC Immunity”
- Interference emission: DIN EN 61000-6-4 “EMC Emission”
- Vibration and shock resistance: DIN EN 60068-2-8:2008 “Vibration”, DIN EN 60068-27:2010 “Shock”
Manufacturer Information: Helmholz GmbH & Co. KG, Hannberger Weg 2, 91091 Großenseebach, Germany. Contact: Phone +49 9135 7380-0, Fax +49 9135 7380-110, Email [email protected], Website www.helmholz.de
See more
Catalog excerpts
Helmholz COMPATIBLE WITH YOU v TB20-C, Bus coupler Modbus/TCP Modbus/TCP Anderungen und Irrtumer vorbehalten. 02-2019 Helmholz GmbH & Co. KG | Hannberger Weg 2 | 91091 Groftenseebach | Germany Phone +49 9135 7380-0 | Fax +49 9135 7380-110 | [email protected] | www.helmholz.d
Open the catalog to page 1
Helmholz COMPATIBLE WITH YOU Helmholz GmbH & Co. KG | Hannberger Weg 2 | 91091 Groftenseebach | Germany Phone +49 9135 7380-0 | Fax +49 9135 7380-110 | [email protected] | www.helmholz.de Anderungen und Irrtumer vorbehalten. 02-2019
