Grommet

Product catalog summary

Overview: The document provides detailed specifications for various types of grommet strips used in cable management, focusing on materials such as Polyethylene (PE), Polyamide 6 (PA6), Polytetrafluoroethylene (PTFE), and Flexible Polyvinyl Chloride (PVC). These products are designed for optimal protection of cables and wires at panel edges.

Specifications:

Polyethylene (PE) Grommets: Available in sizes for panel thicknesses from .016″ to .520″. Operating temperature ranges from -22 °F to +176 °F.
Polyamide 6 (PA6) Grommets: Similar size range as PE, with an operating temperature from -76 °F to +203 °F.
Polytetrafluoroethylene (PTFE) Grommets: Offers a higher temperature range from -76 °F to +500 °F and is non-burning.
Flexible PVC Grommets: Cadmium-free, with a temperature range from -85 °F to +221 °F and a UL94 V0 flammability rating.

Product Features:

Flexiform grommets are designed for easy installation without tools or adhesives and can be cut to length, minimizing waste.
Suitable for use on various materials including wood, steel, aluminum, plexiglass, and glass.
Self-extinguishing PVC grommets ensure safety and flexibility.

Applications: These grommet strips are used for routing and protecting cables in various environments, ensuring safety and durability.

Ordering Information: Each product is identified by an Article No., Part No., and Type, which should be used for ordering and specification purposes. Dimensions are approximate and subject to change.

Catalog excerpts

Optimal protection of cables and wires at panel edges.

Open the catalog to page 1

Flexiform grommet strip Product Selection Article No.Part No.TypePanel ThicknessWidth (W)Width (W2)Width(W3)Width(W4)Height (H)Height(H2)Pkg.Qty.in. (mm)in. (mm)in. (mm)in. (mm)in. (mm)in. (mm)in. (mm)ft.(Meters) Flexible Polyvinyl Chloride, cadmium free (PVC) 800-00004 SM1BK75MT SM1.03937 Т3 - .07874 ″ (1.0 - 2.0).1969 ″ (5.0).03937 ″ (1.0).07 ″ (1.8).165 ″ (4.2).248 ″ (6.3).192 ″ (4.9)246.1 ft (75) > Dimensions are approximate and subject to technical changes. Use Part No. for ordering and Type for specification purposes.

Open the catalog to page 2
