Product catalog summary

Wall Mount Fiber Enclosures
HellermannTyton offers wall mount fiber enclosures designed for LAN applications. These enclosures are fully enclosed, lockable, and support up to two or four modular adapter panels and up to two splice trays. They include cable management features to limit bend radius and provide strain relief. The 12/16 port version is fully enclosed with an optional lock, while the 24/32 port version has separate entry for provider and user sides.

Rack Mount Fiber Enclosures
The new rack mount fiber enclosures support up to 192 fibers and feature front slide-out trays for easy access. They fit into 19” or 23” racks and include cable management accessories. The enclosures come in various sizes, accepting different numbers of adapter panels and splice trays.

Adapter Panels
HellermannTyton provides modular adapter panels with various adapters like ST, SC, MTRJ, and LC. These panels are assembled with industry-standard adapters and are easily installed into enclosures using snap lock fixtures.

Fiber Splice Tray
The fiber splice tray organizes and protects 12 fusion splices within rack mount enclosures. It features smooth radiused sides to prevent fiber damage and includes a removable cover for protection.

Fiber Optic Cable Assemblies
Available in various lengths, these assemblies use standard connectors like ST, SC, MTRJ, and LC. They are manufactured to high performance standards, with each assembly tested for insertion and return loss.

Fiber Modules
Modules for ST, SC, LC, and MTRJ multimode/single mode fibers are available for HellermannTyton’s wallplates and faceplates. They come in different colors and configurations.

Connectors
SC, ST, and LC multimode and single mode connectors are available for field and factory installation. They use zirconia ceramic ferrules for consistent end face geometry.

Accessories
Accessories include the Fiberclean system for cleaning connectors, a multi-function fiber optic stripper, and termination kits for connector installation. These kits contain all necessary tools and materials for terminating connectors.

Catalog excerpts

Enclosures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40-41Adapter Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42Fiber Splice Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42Fiber Optic Cable Assemblies . . . . . . . . . . . . . . . . . . .43Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44 Fiber Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45-46 >

Open the catalog to page 1

Part NumberDescriptionDimensionsPkg. Qty. FAPB Modular Adapter Blank Panel5.09֔(H) x 1.125(W)1 FAP6MMST Modular Adapter Panel Loaded with 6 ST MM/SM Adapters5.09Ԕ(H) x 1.125(W)1 FAP6SMMSC Modular Adapter Panel Loaded with 6 Simplex SC MM/SM Adapters5.09Ԕ(H) x 1.125(W)1 FAP3DMMSC Modular Adapter Panel Loaded with 3 Duplex SC MM/SM Adapters5.09Ԕ(H) x 1.125(W)1 FAP6DMMSC Modular Adapter Panel Loaded with 6 Duplex SC MM/SM Adapters5.09Ԕ(H) x 1.125(W)1 FAP6DMMLC Modular Adapter Panel Loaded with 6 Duplex LC MM/SM Adapters5.09Ԕ(H) x 1.125(W)1 FAP6MTRJ Modular Adapter Panel Loaded with 6 MTRJAdapters5.09Ԕ(H)...

Open the catalog to page 4

FCSCSMFCST FCSTSMFCSC Pkg Part NumberDescriptionQty. FCSC SCMultimode Fiber Connector 1 FCSCSM SCSingle Mode Fiber Connector 1 FCST STMultimode Fiber Connector 1 FCSTSM STSingle Mode Fiber Connector 1 FCLC LC Multimode Fiber Connector1 FCLC > Pkg Carton Part NumberDescriptionQty.Qty. (A) FIBERINSERT-X ST Fiber Adapter Module125(B) SCINSERT-X SC Fiber Adapter Module125(C) LCINSERT-X LC Duplex Fiber Adapter Module125(D) MTRJINSERT-X MTRJ Fiber Module125(E) FPMISC-X SC Duplex Adapter for Modular 11Faceplate Insert, 1.5U Replace "X" in the part number with the following lettersfor desired color:...

Open the catalog to page 6

Pkg.Part NumberDescriptionQty. HTFS Multi-function Fiber Optic Stripper1 > Pkg. Part NumberDescriptionQty. FO1 Fiberclean System Kit1 Kit FO1REF Ultra-White Film Refills1 Roll >

Open the catalog to page 7
