This section provides an overview of HellermannTyton's patch panels, focusing on Category 6 and Category 5e panels designed for high performance and flexibility in network cabling solutions.
These panels feature modular printed circuit boards for individual port replacement, a rear cable manager, a patented slide labeling system, and compatibility with T568A and T568B wiring. Available in 24 and 48 port configurations.
Exceed Category 6 specifications with PowerSum ACR up to 400 MHz, supporting data rates up to 4.8 Gb/s. Available in AlphaSnap and Universal styles.
Available in 12, 24, and 48 port versions, featuring replaceable 6 port modules and Rack-Snap Inserts for easy installation. Support both T568A and T568B wiring.
The MegaBand and AlphaSnap lines comply with Category 5e standards, supporting up to 200 MHz, featuring modular PCBs and a slide labeling system.
Convert 25 pair cables to 12 RJ45 ports, suitable for LAN applications like 100 Base-T, available in 24 and 48 port versions.
Designed for voice applications, offering 50 pair cables in an RJ11 presentation with Krone style punch down blocks.
Accept various modules for flexibility in network configurations.
Details HellermannTyton's modular jacks and connectors for multimedia installations, suitable for coax, voice, audio, video, and fiber, mountable on standard EIA 19" racks.
Pre-numbered modular patch panels in configurations of 12, 16, 24, 32, and 48 ports, with a 1U design for increased density and easy patch cord management.
Designed for HellermannTyton shielded modular jacks, providing superior noise and EMI protection, featuring a slide-out tray for easy rear access.
Support Category 6 cabling applications, available in various configurations, ETL tested for compliance.
Designed for data and voice applications, offering an economical solution with or without standoff legs.
Used in equipment rooms and wiring closets for connecting voice and data cables, with accessories like bridging clips and protective covers.
Ideal for zone cabling solutions, allowing flexibility in cabling design options.
Category 6 and Category 5e patch cords with strain relief boots, available in various lengths and colors.
Available with 12 RJ45 leads to each 25 pair male connector, suitable for 100 Base-T hubs, offered in straight or angled configurations.
Details HellermannTyton's network cabling solutions, focusing on cross-connect products, patch cords, telco cable assemblies, and termination tools.
- 110 to RJ45 Category 5 Patch Cords: Connect network equipment to 110 connecting blocks, available in T568A or T568B wiring configurations.
- 110 to 110 Category 5 Patch Cords: Designed for use between 110 termination blocks, ensuring high-performance connections.
- 100 Base-T telco cable assemblies with 25 pair stranded cable, available in straight or 120º angled orientations.
- IT110EX: Spring-loaded termination tool with adjustable impact pressure, suitable for 110 and 66 block blades.
- IT1105: Combination impact tool for seating and cutting UTP cable on 110 wiring blocks.
- HTEXWS: Expert wire stripping tool, adjustable for various cable types.
- HTWS: Compact wire stripper and IDC insertion tool.
Ergonomically designed to facilitate the punch down process for modular jacks and patch panels.
Includes a detailed product selection guide with part numbers, descriptions, and quantities for each item.
Catalog excerpts
