Product catalog summary

Material Specifications:
The document specifies the use of Polyamide 6.6 (PA66) for cable tie mounts, which can operate continuously between -40 °F to +185 °F (-40 °C to +85 °C). The material has a flammability rating of UL94 V2, excluding adhesive components.

Product Overview:
HellermannTyton offers a variety of cable tie mounting bases designed for bundling and securing cables. These mounts are available in different configurations, including 2-way and 4-way screw mounts, as well as adhesive mounts. The mounts are suitable for various cable tie series, ranging from T18 to T150.

Mounting Options:

2-Way Screw Mounts: Secured with a single screw, allowing cable ties to be inserted from two sides.
4-Way Screw Mounts: Secured with two screws (four for MB2.5), allowing cable ties to be inserted from all four sides.
Adhesive Mounts: Available with rubber-based or acrylic adhesive, providing an alternative to screw mounting, especially in high-temperature, chemical, or UV-exposed environments.

Product Selection:
Detailed specifications for various cable tie mounts are provided, including dimensions, color options, and packaging quantities. Each product is identified by an article number and part number, with dimensions in both inches and millimeters.

Application Recommendations:
Adhesive mounts are recommended for applications where environmental factors favor adhesive use. The CTM series is noted for its flexibility, accommodating different cable tie sizes and securing with a single screw.

Key Considerations:

Dimensions are approximate and subject to change.
Use the part number for ordering and the type for specification purposes.
Select the appropriate mount based on specific application requirements, such as environmental conditions and space constraints.

Material Data: Cable tie anchor plates are made from Polyamide 6.6 (PA66) and a UV-resistant variant, operating continuously between -40 °F to +185 °F (-40 °C to +85 °C) with a flammability rating of UL94 V2.

Specifications: Anchor plates feature slotted mounting holes for easier alignment and secure fastening with screws. The CTAP2 model allows for an additional screw for enhanced stability and is designed to be used perpendicularly to the wire bundle.

Product Selection: Detailed specifications for various cable tie mounts are provided, including dimensions, part numbers, and packaging quantities. Suitable for both indoor and outdoor applications.

Lashing Tie Mounts: Designed to snap into the T250 lashing tie, recommended for wall mount cable applications. The tie head is assembled perpendicular to the mount, with the strap parallel when inserted.

Masonry Mounts: Provide a permanent method for attaching wires and cables to masonry surfaces, suitable for both indoor and outdoor use, installed by tapping into predrilled holes.

Cable Tie Mounting Plates: Allow multiple cables to be run in parallel, secured with two screws, with cables attached using a cable tie through available slots.

Catalog excerpts

Adhesive mounts are supplied in pairs connectedtogether on an adhesive liner. 4-way, MB3, MB4 and MB5 mounts Material Data >

Open the catalog to page 1

Product Selection Article No.Part No.TypeCableTieSeriesMounting Hole Max. PanelThicknessLength (L)Width (W)Height (H)ColorPkg.Qty.in. (mm)in. (mm)in. (mm)in. (mm)in. (mm) 151-27000 LKCRF19C2 LKCRF1T18 -T50.250 آ3 (6.35).134 ″ (3.4).938 ″ (23.82).470 ″ (11.94).157 ″ (3.99)Natural 100151-27009 LKCRF19H4 LKCRF1.250 ″ (6.35).134 ″ (3.4).938 ″ (23.82).470 ″ (11.91).157 ″ (3.99)Natural 500 > Dimensions are approximate and subject to technical changes. Use Part No. for ordering and Type for specification purposes.

Open the catalog to page 4
