partial flow cooler ACIP

Product catalog summary

Overview: The ACIP series partial flow cooler is designed for hydraulic applications, offering benefits such as easy retrofitting, extended oil and component life, and high flexibility in pump choice. It features short delivery times due to intelligent warehousing.

Ordering Code: The ordering code for the ACIP series includes specifications for cooler size, displacement, power, fan speed, and series type. For example, ACIP-11-19-1,1-4 indicates a cooler size of 11, displacement of 19 cm³, power of 1.1 kW, and a 4-pole fan speed.

Product Features: The ACIP cooler system integrates a motor pump unit for efficient and continuous oil cooling. It operates independently from the main hydraulic power unit and includes features such as a 230/400 V drive motor, gear pump with 4 bar operating pressure, and a permissible viscosity range of 10 - 300 mm²/s.

Technical Specifications: The document provides detailed dimensions and technical data for various models, including oil flow rates, cooling capacity, power requirements, and weight. For instance, the ACIP-11-19-1,1-4 model has an oil flow of 27 l/min, cooling capacity of 0.16 kW/K, and weighs 37 kg.

Additional Information: The document notes that the current publication supersedes previous ones and reserves the right for changes. It also provides contact information for HBE GmbH and mentions certifications like ISO 9001/14001/45001.

Catalog excerpts

: hydraulic components fluid technology solutions

Open the catalog to page 1

SERIES ACIP The new cooler system ACIP is optimised for a wide range of hydraulic applications. An integrated motor pump unit makes it possible to cool the oil efficiently and continuously in a separate circuit. The cooling process is working independently from the operation condition of the main hydraulic power unit. Product features • Oil-air cooler ACI with motor & pump in one unit • Drive motor 230/400 V, 50 Hz, 1450 min-1 • Gear pump, operating pressure: 4 bar • Bellhousing and coupling • Continuous cooling process • Permissible viscosity range: 10 - 300 mm2/s • Max. operating temperature...

Open the catalog to page 2

Cooler size

Open the catalog to page 3

Explore our product diversity HBE GmbH Hönnestraße 47 58809 Neuenrade / Germany TÜV NORD CERT GmbH Phone +49 (0) 23 94 / 616-0 [email protected] www.hbe-hydraulics.com

Open the catalog to page 4
