Condensed Product Guide

HAYWARD® FLOW CONTROL – DEFINE, DESIGN, DELIVER... For more than 50 years, Hayward Flow Control’s thermoplastic fluid handling products and solutions have proven to excel in the harshest environments. Thousands of customers worldwide have installed our products into aggressive and corrosive systems, as well as delicate life support systems where the strictest chemical balance is required. We understand the specific demands of industrial piping and are committed to offering advantageous products for your application that will keep your systems working. Hayward Flow Control products carry an...

TB Series True Union Ball Valves 1/4" TO 3/8" PVC AND 1/2" TO 2" PVC, CPVC AND GFPP KEY FEATURES • PVC, CPVC and GFPP • Full Port Design • Reversible PTFE Seats • Double O-Ring Stem Seals • Easily Actuated • NSF/ANSI 61 Listed (PVC and CPVC) • Lockouts Available • 2" Square Operating Nut • Stem Extensions • neumatic and Electric Actuators P • Spring Return Handle SELECTION CHART SIZE Now Available in Platinum GFPP! PVC or CPVC Socket and Threaded FPM or or Flanged* EPDM PRESSURE RATING * All flanged valves are rated to 150 PSI @ 70°F Non-Shock TB Series True Union Ball Valves 2-1/2" TO 6"...

TBZ Series “Z-Ball” True Union Ball Valves 1/2" TO 6" PVC AND CPVC KEY FEATURES • PVC and CPVC • Full Port Design • Reversible PTFE Seats • Double O-Ring Stem Seals • For Sodium Hypochlorite Applications • Adjustable Seat Retainer • Lockouts Available • Stem Extensions • Spring Return Handle • neumatic and P Electric Actuators • 2" Square Operating Nut SELECTION CHART SIZE Socket and Threaded or Flanged** 2-1/2" – 4" PVC or CPVC Socket, Threaded (DN63 – DN100) or Flanged** 6" * Flanged PRESSURE RATING 250 PSI @ 70°F Non-Shock 235 PSI @ 70°F Non-Shock 150 PSI @ 70°F Non-Shock ** All flanged...

TW Series Three-Way True Union Ball Valves 1/2" TO 6" PVC AND CPVC KEY FEATURES • PVC and CPVC • Position Indicator • Easily Actuated • PTFE Seats • FPM or EPDM O-Rings • Double O-Ring Stem Seal • Lockouts Available • Pneumatic and Electric Actuators • Cross-Flow Ball • NT Ball • TP Ball SELECTION CHART SIZE Socket, Threaded or Flanged Flanged PRESSURE RATING LA Series Lateral Three-Way True Union Ball Valves 1/2" TO 6" PVC AND CPVC KEY FEATURES • PVC and CPVC • PTFE Seats • FPM or EPDM O-Rings • Double O-Ring Stem Seal • Simplifies Lateral Connections • eplaces Valve/Tee R Connection...

QV Series QIC2 ™ Compact Ball Valves 1/2" TO 2" PVC KEY FEATURES • Gray PVC • ugged, Compact and R Lightweight Design • Full Port Design • PTFE Seats • EPDM O-Ring Seals • Low Torque, Easy 1/4-Turn Operation • No Integral Parts to Replace • Perfect for OEM Requirements SELECTION CHART SIZE PRESSURE RATING Valve-Safe Lockouts FOR BALL VALVES UP TO 6" KEY FEATURES (A) • For Ball Valves up to 6" • atches and Lockable in L Open/Close Position • Simple Trigger Mechanical Design • Can Use with Lockout/Tagout Hasp • PP Housing Material • For All Ball Valves up to 6" • Use with up to 3 Padlocks

TBB Series Commercial True Union Ball Valves 1/2" TO 4" PVC, CPVC, PP AND PVDF SELECTION CHART MATERIAL Socket, Threaded or Flanged* • PVC, CPVC, PP and PVDF • Full Port Design • FPM or EPDM Seals • PTFE Seats • Double O-Ring Stem Seals • Adjustable Seat Retainer PRESSURE RATING * All flanged valves are rated to 150 PSI @ 70°F Non-Shock QTA Series Commercial True Union Compact Ball Valves 1/2" TO 2" PVC KEY FEATURES • Gray and White PVC • True Union End Connections • Rated at a Full 150 PSI • Santoprene® (TPV) Seats • EPDM O-Ring Seals • No Internal Parts to Replace • Torque Easy Low...

SW Series Swing Check Valves 3" TO 6" PVC, CPVC AND GFPP AND 8" PVC AND GFPP KEY FEATURES • PVC, CPVC and GFPP • High Temperature/ Pressure Ratings • Two-In-One Seal Design • Built-In Flange Seals • Two Drain Ports • Self-Aligning Clapper Seals • High Cv Rating and Full Flow Design SELECTION CHART SIZE PRESSURE RATING OPTIONS • ounterweight for C Closing Assistance WCV Series Full Pattern Wafer Check Valves 2" TO 8" PVC AND CVPC (GFPP COMING SOON) KEY FEATURES • obust Full Pattern Body R • VC and CPVC (GFPP Coming Soon) P • o Special Spacers or Flanges Required N • igh Cv Rating Equal to...

TC Series True Union Ball Check Valves 1/4" TO 3/8" PVC, 1/2" TO 2" PVC, CPVC AND PP AND 2-1/2" TO 6" PVC AND CPVC KEY FEATURES • PVC, CPVC and PP • For Horizontal or Vertical Installation • 1/2" to 6" are Sure Block Design • Square Cut Seat for Positive Sealing • Seats with Minimum Back Pressure • /4" and 3/8" are 1 Trim Check Design SELECTION CHART SIZE PRESSURE RATING and Threaded PVC or CPVC Socket Flanged**** or PP** • Foot Valve Screens Threaded Socket, Threaded or Flanged * Trim Checks ** 2" PP is rated to 100 PSI @ 70°F Non-Shock **** All flanged valves are rated to 150 PSI @ 70°F...

BY Series Butterfly Valves 1-1/2" TO 8" PVC, CPVC AND GFPP AND 10" TO 12" GFPP KEY FEATURES • VC, CPVC and GFPP P Bodies and Discs • PM, EPDM and Nitrile F Seat Materials • eets ANSI Steel Shaft B16.10 M Face-to-Face Dimensions* • ully Supported Flange F Bolt Holes • -Notch Seal of Liner V to Body • even-Position Lever S Handle or Gear Box Operator** • 16 Grade Stainless 3 Steel Shaft • Dead End Service Fully Rated • Stem Extensions • Gear Operators • neumatic or Electric Actuators P • Stainless Steel Lugs • 2" Square Operating Nut • Titanium or Hastelloy® Shaft • hain Operator for Gear Box...
