STAR 10

Product catalog summary

Overview: The STAR 10 Vertical Masts are designed for optimal agility in confined working areas, featuring advanced electric drive systems and durable construction materials.

Key Features:

Progressive Electric Drive: Utilizes AC motors for efficient operation.
Durability: Enhanced with unbreakable composite hoods and increased longevity of components such as pins and bushes.
Transportability: Equipped with forklift tine pockets for versatile transport solutions.
Maintenance and Downtime: Features zero tail swing and a 3-meter outreach vertical jib to minimize maintenance needs.
Longer Lifetime: Incorporates maintenance-free brushless AC motors and Haulotte Activ'Screen for onboard diagnostics.
Battery Management: Haulotte Activ'Energy Management ensures minimal battery maintenance with an automatic centralized water filling system.

Technical Specifications:

Working Height: 10 meters
Platform Height: 8 meters
Lift Capacity: 200 kg for both inside and outside use
Horizontal Outreach: 3 meters
Platform Size: 0.78 x 0.98 meters
Drive Speed: 0.6 - 5 km/h
Turning Radius: 1.88 meters
Gradeability: 25%
Power Source: 24 V - 250 Ah traction batteries

Standard Equipment: Includes features such as forklift tine pockets, towing hooks, non-marking tires, emergency stop buttons, and load controller in the platform.

Options and Accessories: Offers additional features like Haulotte Activ’Shield Bar, power and air lines in the platform, biodegradable oil, and telematics readiness.

Catalog excerpts

VERTICAL MASTS STAR 10 OPTIMAL AGILITY IN CONFINED WORKING AREAS > Progressive electric drive AC motors > Zero tail swing > 3 m outreach vertical jib MINIMAL MAINTENANCE & DOWNTIME > Maintenance free brushless AC motors > Haulotte Activ'Screen (onboard diagnostic) > Haulotte Activ'Energy Management takes scare of your batteries > Almost 0 battery maintenance: automatic & centralized waterfilling system LONGER LIFE TIME > Unbreakable hoods in composite material > Durability multiplied by 3 on pins, bushes, non-painted parts and fastening hardware SMART TRANSPORTABILITY > Versatile and effective transport solutions with forklift tine pockets > 25 % gradeability to easily climb truck ramps

Open the catalog to page 1

STANDARD EQUIPMENT VERTICAL MASTS TECHNICAL DATA Working height Platform height Horizontal outreach Lift capacity - inside Lift capacity - outside Platform size 0 Length 0 Width 0 Height - stowed Tailswing 0 Wheelbase 0 Ground clearance Max driveable platf. height Drive speed proportional Turning radius - outside Turntable rotation Vertical jib rotation Tilt alarm Gradeability > Haulotte Activ'Energy Management: Smart CAN charger > Automatic centralized battery filling > 24 V electric drive brushless AC motors > 24 V - 250 Ah traction batteries > Battery charge indicator > On-board diagnostic...

Open the catalog to page 2
