Overview: HAUG ionization systems are designed for areas with potentially explosive atmospheres to eliminate electrostatic charges that can interfere with production processes. These systems are crucial in industries where materials with poor electrical conductivity are processed, such as paint plants and printing machines.

Product Specifications: The ionization units are available as hand-held units (RI Ex M/V) with a compressed air gun or for fixed installation (RI Ex O). They are suitable for use in environments with gases of explosion group IIA and temperature classes T4 to T6. The power packs, such as the EN 92 Ex and Multistat Ex, are designed to be used in zones 1 or 2 of potentially explosive atmospheres and comply with European ATEX directives.

Key Features: The power packs are equipped with high-voltage ports for connecting ionizing units and are housed in flameproof enclosures. They include features like an electronic watchdog function, automatic fault alarm, and high-voltage monitoring. The ionizing bars and ring ionizers are designed to eliminate electrostatic charges effectively.

Applications: HAUG ionization systems are used in various industries, including graphical industries (screen, tampon, and offset printing machines) and paint shops (automotive paint applications, painting of plastic parts). The systems consist of a power pack that transforms the rated voltage required for the ionizing unit and various ionizing units connected to the power pack.

Technical Data: The power packs have a nominal input voltage of 115 V or 230 V, with an output voltage of approximately 7 – 8 kV. They consume about 40 VA of power and have an output short-circuit current of 3 to 5 mA. The ambient operating temperature ranges from +5°C to +40°C, with storage temperatures from -15°C to +60°C.

Accessories: Special accessories include various connection options for ionizing bars and ring ionizers, air hoses, filter control valves, and protective tubes for high-tension cables. Air consumption figures are available upon request.

Contact Information: HAUG GmbH & Co. KG in Germany and HAUG Biel AG in Switzerland provide contact details for further inquiries and support.
