Overview
HAUG Ionization systems are designed to eliminate electrostatic charges that can disrupt production processes by attracting dust and other quality-reducing substances. The company has over 45 years of experience in research, development, and production to control this phenomenon.

One-Point-Ionizer
The One-Point-Ionizer is developed to discharge extremely small parts by neutralizing electrostatic spot charges through the emission of positive and negative ions. It is particularly suitable for installation in confined spaces and is easy to set up by connecting the electrode plug to the high voltage transformer without the need for additional tools. It is widely used in fields such as medical technology and can be equipped with compressed air for enhanced performance.

Warning
The ionizer pin carries high voltage and should not be touched while the unit is switched on.

Cleaning and Maintenance
Regular cleaning with HAUG's special cleaning agent and cleaning set is recommended to maintain the ionizer's effectiveness.

Technical Specifications
- Type: Order-No.: 03.8510.000
- Operating Temperature: +5 °C to +50 °C
- Storage/Transport Temperature: -15 °C to +60 °C
- Optimum Effective Distance: 30 mm
- Smallest Bending Radius (Cable): R 50
- Diameter: 16 mm
- Length: 45 mm
- Connectable Lengths: Up to 18m depending on the model

Accessories
Includes a holder with a plate and an anti-kinking sleeve. Suitable power packs are available for different connection lengths.
