• Customized foil layout for user-specific designs.
• Graphic display with a resolution of 128 × 64 dots, featuring a white backlight, with an option for RGB backlight.
• Equipped with 12 superbright LEDs for symbol illumination.
• Includes a metal installation bracket for easy mounting in a 102 mm hole.
• Sealed to meet IP67 standards, ensuring protection against dust and water.
• Features a CAN interface for connectivity.

• Operating temperature range: -20°C to +80°C.
• Protection type: IP67, indicating high resistance to environmental factors.
• Housing material: PA6.6 with 30% glass fiber (GF) for enhanced durability.
• Supply voltage range: 7.0 to 60 V DC.
• Power consumption: 300 mA at 12 V DC with all LEDs illuminated.
• Weight: 170 grams.
• Dimensions: 116 mm in diameter and 33 mm in height.
• Installation hole size: 102 mm.

Technical data is subject to change without notice. For further inquiries, contact HATOX GmbH at Von-Drais-Str. 9, 75217 Birkenfeld, or via phone at +49 (0)7231 13323-0, or email at [email protected]. More information is available on their website www.hatox.com.
