Technical Specifications:
- Supply Voltage: Single-phase 100–230 V AC ±10%, Three-phase 400 V
- Stroke: Customizable upon request
- Protection System: IP40 to IP54
- Protection Class: Class 1
- Duty Cycle: 35 seconds "on", 300 seconds "off"
- Operation System: Electric, low voltage via control box
- End Position: Mechanical limit stop
- Position Control: Analogous distance control (0–10 V, 0–20 mA) - optional for SH 95

Performance Data:
- Force: 2000 to 10000 N
- Frequency: 50 Hz and 60 Hz
- Speed: 3.5 to 75.0 mm/s depending on frequency and force

Control Box Option:
- Capable of operating up to four linear actuators
- Includes a low voltage handset

Additional Notes:
- Fixing dimensions are dependent on load
