Linear actuator KL 95
1 / 2 PagesView full catalog
Linear actuator KL 95
Product catalog summary
Technical Specifications:
- Supply Voltage: Single-phase 100–230 V AC with a tolerance of +/- 10%, Three-phase 400 V.
- Stroke: Customizable upon request.
- Protection System: IP 55, IP 66.
- Protection Class: Class 1 or 2.
- Duty Cycle: 35 seconds 'on', 300 seconds 'off' (S3–12% ED, SD–300s).
- Operation System: Electric, pneumatic, or low voltage via control box.
- End Position Control: Limit switches (microswitch).
- Electronic Position Control: Optional analogous distance control (0–10 V, 0–20 mA).
- Security Option: Declutching system for downward movement.
- Can operate up to four linear actuators.
- Includes a low voltage handset.
- Force: 2000–10000 N.
- Frequency: 50 Hz or 60 Hz.
- Speed: 3.5–63.0 mm/s at 50 Hz, 4.2–75.0 mm/s at 60 Hz, 11 mm/s at 50 Hz for 10000 N.
