Wireway & Trough Quality Enclosures. Service Excellence. © Hammond Manufacturing Canada: 519.822.2960 or 905.456.3770 USA: 716.630.7030 Data Subject to change without notice 318

Wireway & Trough Quality Enclosures. Service Excellence. © Hammond Manufacturing Canada: 519.822.2960 or 905.456.3770 USA: 716.630.7030 Data Subject to change without notice Technical references and DXF downloads available at www.hammfg.com All dimensions in inches unless specified otherwise 320 Lay-In Wireway Application Designed to enclose and protect electrical wiring from dirt, dust, oil and water. All sections and fittings are completely open on each side to allow wires and cables to be placed into the wireway without “pulling through”. Standards UL 870 Type 1 (unless marked1) CSA Type 1...

Wireway & Trough Quality Enclosures. Service Excellence. © Hammond Manufacturing Canada: 519.822.2960 or 905.456.3770 USA: 716.630.7030 Data Subject to change without notice Technical references and DXF downloads available at www.hammfg.com All dimensions in inches unless specified otherwise 322 Lay-In Wireway 1485 Series Lay-In Wireway - NEMA 12

Wireway & Trough Quality Enclosures. Service Excellence. © Hammond Manufacturing Canada: 519.822.2960 or 905.456.3770 USA: 716.630.7030 Data Subject to change without notice Technical references and DXF downloads available at www.hammfg.com All dimensions in inches unless specified otherwise 323 Lay-In Wireway Typical Straight Section Angle Sealing Plate Part No. Size 1485BS9 2.5 x 2.5 1485CS9 4 x 4 1485DS9 6 x 6 1485ES9 8 x 8 1485FS9 12 x 6 Maintains ratings on CSA and UL approved wireway Partition (Barrier) Kit Divides wireway into two or more compartments. Barriers are fastened to wireway...

Wireway & Trough Quality Enclosures. Service Excellence. © Hammond Manufacturing Canada: 519.822.2960 or 905.456.3770 USA: 716.630.7030 Data Subject to change without notice Technical references and DXF downloads available at www.hammfg.com All dimensions in inches unless specified otherwise 324 Lay-In Wireway Adjustable Fitting Allows on site length adjustment of 2" to 7" • Cut-Off Fitting (Lay-In) Body comes in two pieces. Cut-off one piece, shorten cover, and weld together. Includes angle sealing plate. • • Cut-Off Fitting (Non Lay-in) For lengths up to 12”. Cut off body and weld on flange....

Wireway & Trough Quality Enclosures. Service Excellence. © Hammond Manufacturing Canada: 519.822.2960 or 905.456.3770 USA: 716.630.7030 Data Subject to change without notice Technical references and DXF downloads available at www.hammfg.com All dimensions in inches unless specified otherwise 325 Lay-In Wireway 1485 Series Lay-In Wireway - NEMA 12 90° Elbow Top Opening Part No. Size M 1485B9N 2.5 x 2.5 4.25 1485C9N 4 x 4 5.00 1485D9N 6 x 6 6.00 1485E9N 8 x 8 7.00 1485F9N 12 x 6 9.00 One flat sealing plate included 90° Elbow Inside Opening Part No. Size J 1485B9P 2.5 x 2.5 4.25 1485C9P 4 x 4 5.00...

Wireway & Trough Quality Enclosures. Service Excellence. © Hammond Manufacturing Canada: 519.822.2960 or 905.456.3770 USA: 716.630.7030 Data Subject to change without notice Technical references and DXF downloads available at www.hammfg.com All dimensions in inches unless specified otherwise 326 Lay-In Wireway Tee Fitting Outside and Top Opening Part No. Size H M 1485BTQ 2.5 x 2.5 8.50 4.25 1485CTQ 4 x 4 10.00 5.00 1485DTQ 6 x 6 12.00 6.00 1485ETQ 8 x 8 14.00 7.00 Two flat sealing plates included Tee Fitting Top Opening Part No. Size H M 1485BTN 2.5 x 2.5 8.50 4.25 1485CTN 4 x 4 10.00 5.00 1485DTN...

Wireway & Trough Quality Enclosures. Service Excellence. © Hammond Manufacturing Canada: 519.822.2960 or 905.456.3770 USA: 716.630.7030 Data Subject to change without notice Technical references and DXF downloads available at www.hammfg.com All dimensions in inches unless specified otherwise 327 Lay-In Wireway 1485 Series Lay-In Wireway - NEMA 12 Drop Hanger Bracket Hanger Part No. Size R W 1485BL1 2.5 x 2.5 9.25 4.50 1485CL1 4 x 4 11.75 6.00 1485DL1 6 x 6 15.25 8.12 1485EL1 8 x 8 20.56 12.12 Does not meet CSA or UL requirements Part No. Size R W 1485BL2 2.5 x 2.5 4.62 4.37 1485CL2 4 x 4 6.12...

Wireway & Trough Quality Enclosures. Service Excellence. © Hammond Manufacturing Canada: 519.822.2960 or 905.456.3770 USA: 716.630.7030 Data Subject to change without notice Technical references and DXF downloads available at www.hammfg.com All dimensions in inches unless specified otherwise 328 Wiring Trough Application Designed to enclose and protect multiple wiring junctions from dirt, dust, oil and water. Standards UL 870 Type 1 CSA Type 1 Complies with NEMA Type 12 JIC EGP-1-1967 JIC EMP-1-1967 IEC 60529, IP54 • • • • • • • • Construction Formed 14 gauge steel. Smooth continuously welded...

Wireway & Trough Quality Enclosures. Service Excellence. © Hammond Manufacturing Canada: 519.822.2960 or 905.456.3770 USA: 716.630.7030 Data Subject to change without notice Technical references and DXF downloads available at www.hammfg.com All dimensions in inches unless specified otherwise 330 Pull Through Wireway Application Designed to enclose and protect electrical wiring from dirt, dust, oil and water. Ideal for connecting machines to control panels or power sources. Standards UL 870 Type 1 (unless marked1) CSA Type 1 (unless marked1) Complies with NEMA Type 12 JIC EMP-1-1967 JIC EGP-1-1967...

Wireway & Trough Quality Enclosures. Service Excellence. © Hammond Manufacturing Canada: 519.822.2960 or 905.456.3770 USA: 716.630.7030 Data Subject to change without notice Technical references and DXF downloads available at www.hammfg.com All dimensions in inches unless specified otherwise 332 Pull Through Wireway Typical Nipple Typical Straight Section C=12" Section Part No. C=24" Section Part No. C=36" Section Part No. C=48" Section Part No. C=60" Section Part No. C=120" Section Part No. Size 1487B12 1487B24 1487B36 1487B48 1487B60 1487B120 2.5 x 2.5 1487C12 1487C24 1487C36 1487C48 1487C60...
