Product catalog summary

Introduction
Hammond Manufacturing is the exclusive North American sales partner of ROLEC Gehäuse-Systeme GmbH, a German company renowned for its innovative electronic enclosures. ROLEC, managed by the second generation of the Rose family, continues to provide high-quality enclosure solutions.

aluCASE Specifications
The aluCASE series features modern, high-quality instrument enclosures made from aluminum die-cast. Key features include a shallow lid with a deep body, captive stainless steel lid screws, and a neoprene oil and petrol-resistant gasket. These enclosures are designed for easy installation and provide a high degree of protection (NEMA 4X, IP67).

aluNORM Specifications
The aluNORM series is made from aluminum die-cast and features a shallow lid with a deep body. It includes a neoprene gasket and offers protection up to NEMA 4X, IP65 standards. The design allows for space-saving single-channel mounting and includes internal mounting shelves.

conFORM Specifications
The conFORM series is designed with EMI/RFI protection in mind, eliminating the need for expensive conducting gaskets. It features a shallow lid with a deep body and provides protection up to NEMA 4X, IP66 standards. The enclosures are CSA certified for industrial control equipment.

handCASE Specifications
The handCASE series is designed for heavy-duty handheld use, made from diecast aluminum for strength. It features an ergonomic design, a two-part lid construction, and includes P.C. board standoffs. The smaller sizes come with an ABS plastic battery compartment.

Diecast Aluminum Enclosures
These enclosures are designed to meet IP66 standards, offering protection against dust, oil, and water. They are available in different sizes with stainless steel lid screws and include models with and without battery compartments.

Extruded Aluminum Enclosures (mobileCASE)
These enclosures have a modern, ergonomic design suitable for mobile use and housing P.C. boards. They are available in one-piece (IP65) and two-piece (IP54) versions, constructed from extruded aluminum with diecast aluminum ends.

Non-Metallic Enclosures

starCASE: Made from ABS flame retardant plastic, suitable for environments where metallic enclosures are not ideal. Meets NEMA and IP66 standards.
technoBOX: ABS plastic enclosures with a modern design, providing protection against dust, oil, and water. Meets NEMA and IP66 standards.
technoCASE: ABS plastic with reversible bottom and cover sections, offering high protection and a finished appearance.
polyTOP: Polyester enclosures designed for robust protection, meeting various NEMA and IP standards.
polyDOOR: Polyester enclosures with features like captive screws and oil-resistant gaskets, suitable for industrial control equipment.

Accessories
Cover plates and gaskets are available in flat or collar styles, made from heavy-duty diecast aluminum. Battery kits and cable gland adaptor kits provide additional functionality, while shoulder straps and protective caps enhance portability and protection.

Key Features Across Products
These products offer high protection against environmental factors like dust, oil, and water. They are made from a variety of materials, including aluminum, ABS plastic, and polyester, each offering specific benefits. The products comply with international standards such as NEMA and IP ratings, with options for customization and additional accessories to suit specific needs.

Specifications and Features
The document describes non-metallic enclosures with tongue and groove construction, resistant to oil and petroleum. They include threaded stainless steel inserts for internal mounting and are finished in light beige RAL 7032, Pantone 413. The R130 and R131 series feature spring-loaded stainless steel hinge pins for quick lid removal.

Dimensions
Detailed dimensions for various models in the R130 and R131 series are provided, both with and without integrated hinges. Dimensions are given in both millimeters and inches, covering width, length, and depth.

Additional Resources
Technical references and CAD downloads are available on the Hammond Manufacturing website. Additional literature, including catalogs in English and German, can be requested.

Certifications and Customization
The document mentions the ease of quoting and ordering, with options to modify PDF drawings and AutoCAD files. Customization options include machining, silk screening, hot stamping, special colors, and custom materials for various series.

Protection and Standards
Information on the degree of protection (IP codes) is provided, although the specific details are not clearly summarized in the text.

Contact Information
Contact details for Hammond Manufacturing in the USA and Canada are provided, including addresses, phone numbers, and fax numbers.

Catalog excerpts

Mr. Friedhelm Rose, Ms. Betty Rose, Mr. Matthias Rose. Hammond Manufacturing is proud to be the exclusive North American sales partner ofROLEC Gehuse-Systeme GmbH of Germany.ROLEC was founded in 1987 by Mr. Friedhelm Rose and his son, Mr. Matthias Rose.Mr. Friedhelm Rose developed the fi rst water and dust-tight enclosures over 40 years ago, establishing the very basis of the electronic enclosure industry in Germany. Following Mr. Friedhelm Roses retirement, ROLEC is successfully managed by second generation of the Rose family, Mr. Matthias Rose and Ms. Betty Rose. ROLEC continues to offer innovative...

Open the catalog to page 2

aluCASE Specifi cations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4R190 & R191 Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 aluNORM Specifi cations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6R100 Series - Shallow Lid, Deep Body . . . . . . . . . . . . . . . . . . . . . . . ....

Open the catalog to page 3

Diecast Aluminum Modern, high quality instrument enclosure Material - Aluminum die-cast: GD SI 12 / DIN 1725 Օ Shallow lid, deep body Captive stainless steel lid screws Օ Enclosure can be mounted after closing lid Integrated 1.7 mm recess in lid for membrane keypads Օ and front panels Neoprene oil and petrol resistant - thermoplastic gasket standard. (-40պC up to +120C) Clip-on design covers - to hide mounting & lid screws ڕ (plastic - polyoxymethylene) - grey RAL 7040 Complete with lid captivation devices Degree of protection: NEMA 4X, IP67 Օ Textured polyester powder coat, grey RAL 7040. (can...

Open the catalog to page 4

Diecast Aluminum Material - Aluminum die-cast: G AI SI 12 / DIN 1775 Shallow lid, deep body Օ Captive stainless steel lid screws Neoprene oil and petrol resistant gasket standard. Օ (-40C up to +80ںC) Degree of protection NEMA 4X, IP65, DIN 40050 Temperature Range (-40պC up to +80C) ڕ Single-channel Fastening System. Trouble-free turning 90պ to 90 with square enclosures by synchronous arrangement of channels Special developed external mounting feet made ڕ from zinc-die-cast. Can be turned through 90. The fastening holes have engagement lugs for this purpose. (See accessories) All sizes have inner...

Open the catalog to page 6

Diecast Aluminum Part No.UnitsWidthLengthHeight(Including Lid)ABC Part No.UnitsWidthLengthHeight(Including Lid)ABC mm mm R102-080-000 808040 16032066 > inch 3.23.21.6 R102-164-000 > inch 6.412.82.6 > mm mm R102-082-000 8012040 16048066 > inch 3.24.81.6 R102-166-000 > inch 6.419.22.6 > mm mm R102-084-000 8016040 20020080 > inch 3.26.41.6 R102-200-000 > inch 883.2 > mm mm R102-100-000 10010054 20030080 > inch 442.2 R102-202-000 > inch 8123.2 > mm mm R102-102-000 10015054 20040080 > inch 462.2 R102-204-000 > inch 8163.2 > mm mm R102-104-000 10020054 24024080 > inch 482.2 R102-240-000 > inch 9.69.63.2...

Open the catalog to page 9

Diecast Aluminum Material - Aluminum die-cast: G AI SI 12 / DIN 1775 Shallow lid, deep body Օ Captive stainless steel lid screws Neoprene oil and petrol resistant gasket standard. (-40պC up to +80պC) EMI/RFI gasket is NOT required as lid to box connection is INSIDE the gasket seal. A patented system with special designed Փteeth in the enclosure bottom provide a lasting and corrosion secure shield. Degree of protection NEMA 4X, IP66, DIN 40050 ԕ Temperature Range (-40C up to +80ںC) Separate channel system (outside the seal) Օ Specially developed external mounting feet made from zinc-die-cast....

Open the catalog to page 10

Diecast Aluminum

Open the catalog to page 11

Diecast Aluminum Designed as a heavy duty hand held - manufactured in diecast aluminum for superior strength. Ergonomic design for extended handling without fatigue. Օ Two-part styled lid construction. Top half includes smooth recessed area for membrane, label or silkscreen. Top half powder painted in a silver grey and the bottom half Օ is powder painted in black. P.C. board standoffs are cast into both halves of the enclosure. Mounting screws included. The two smaller sizes include an ABS plastic battery Օ compartment installed and gasketed access bottom lid. Gasketed lid with two piece tongue...

Open the catalog to page 12

Diecast Aluminum Part NumberBatteryCompartment UnitsLengthWidthHeight(Including Lid)Weight ABC R270-080-000 YesInch7.093.151.671 lb. 1.1 oz. mm1808042.4 R270-100-000 YesInch8.663.941.671 lb.7.1 oz. mm22010042.4 R271-100-000 NoInch8.663.942.461 lb. 8.3 oz. mm22010062.4 Technical references and CAD downloads available at www.hammondmfg.com 13 >

Open the catalog to page 13

Modern and ergonomic design Designed to house P.C. boards (not included) or equipment Օ for mobile use Sized for standard Eurocards P.C. boards mount horizontally by sliding into internal slots Օ extruded into the enclosure body Internal height 1.06 (27mm)ԕ Rugged body constructed from extruded aluminum with diecast aluminum ends Silver anodized fi nishՕ Choice of two versions - one piece closed or two piece Փclam shell One piece version is rated to IP 65 (with gasketed end ԕ plates below) Two piece version is rated to IP 54 (with gasketed end plates below) > Extruded Aluminum Diecast End Plates...

Open the catalog to page 14

Extruded Aluminum Part NumberVersionUnitsLengthWidthProfi le WidthL W P R250-080-120 One Pieceinch4.724.653.15 R251-080-120 Two Piece mm12011880 R250-080-160 One Pieceinch6.34.653.15 R251-080-160 Two Piece mm16011880 R250-100-160 One Pieceinch6.35.433.94 R251-100-160 Two Piece mm160138100 R250-100-200 One Pieceinch7.875.433.94 R251-100-200 Two Piece mm200138100 R250-130-180 One Pieceinch7.096.615.12 R251-130-180 Two Piece mm180168130 R250-130-240 One Pieceinch9.456.615.12 R251-130-240 Two Piece mm240168130 Technical references and CAD downloads available at www.hammondmfg.com 15 >

Open the catalog to page 15

Choose either Flat or Collar (used for accepting cables or batteries) style end plates Heavy duty diecast aluminumՕ Painted with textured black powder paint (RAL 9005) Includes cover plates, thermoplastic black gaskets and Օ mounting hardware Sold in Pairs > Extruded Aluminum Part NumberStyleUse With Aluminum Extrusion Part Number Flat Style R580-080-000FlatR250-080-120 or R251-080-120 or R250-080-160 or R251-080-160R580-100-000FlatR250-100-160 or R251-100-160 or R250-100-200 or R251-100-200R580-130-000FlatR250-130-180 or R251-130-180 or R250-130-240 or R251-130-240R581-080-000CollarR250-080-120...
